KEMET ESC686M035AE3AA Aluminum Electrolytic Capacitor
The KEMET ESC series aluminum electrolytic capacitor with a capacitance of 68 µF and a tolerancem of 20% is designed for powering electronic circuits requiring high ripple current. It features a 35 VDC nominal voltage (44 VDC surge) and operates within a temperature range of -40°C to +105°C. With low ESR and a lifespan of at least 2000 hours at 105°C, it is suitable for applications demanding stable performance and durability. Its lead spacing of 2.5mm ensures easy mounting in compact electronic assemblies, making it ideal for power supplies and filtering circuits.
KEMET ESC686M035AE3AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 68 µF
- Capacitance Tolerance: 20%
- Rated Voltage: 35 VDC, Surge Voltage: 44 VDC
- Temperature Range: -40°C to +105°C
- Lead Spacing: 2.5mm ±0.5mm
- Lifespan: 2000 Hours at 105°C
- Dissipation Factor: 12%
- Resistance: 0.22 Ohms at 100kHz
- Ripple Current: 300 mA at 105°C, 100kHz
- Leakage Current: 24 µA at 20°C for 2 minutes
- Impedance Ratio at -25°C: 3
- Impedance Ratio at -40°C: 4
- Packaging: Bulk, Bag, Quantity: 10,000 units
Buy the Buy KEMET Aluminum Electrolytic Capacitor Part Number ESC686M035AE3AA Online
Enhance your electronic designs with the KEMET aluminum electrolytic capacitor featuring a 68 µF capacitance, 35 VDC rating, operating from -40°C to +105°C. This low ESR component is ideal for power filtering and smoothing in various electronic devices. With a lifespan of at least 2000 hours at 105°C, it ensures durability and stability under demanding conditions. Its lead spacing of 2.5mm allows for easy integration into compact assemblies, making it a reliable choice for engineers seeking efficiency and longevity in their projects.
Get KEMET ESC686M035AE3AA today—built for high ripple current and long-term reliability in power supplies and filtering applications.
Frequently Asked Questions
Where can I buy KEMET ESC686M035AE3AA?
You can click on the BUY or RFQ button to purchase ESC686M035AE3AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ESC686M035AE3AA?
You can download the ESC686M035AE3AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ESC686M035AE3AA?
KEMET
