KEMET ESH106M063AC3AA Electrolytic Capacitor
The ESH Series of high-quality aluminum electrolytic capacitors are designed for reliable performance in various electronic circuits. They feature a capacitance of 10 uF with a 20% tolerance, rated at 63 VDC and operating temperatures from -40°C to +105°C. These capacitors are ideal for decoupling, filtering, and bypass applications, offering a lifespan of 2,000 hours and high CV ratings. Constructed with wire leads and a safety vent, they ensure safety and durability in demanding environments, making them suitable for general-purpose and high-reliability uses.
KEMET ESH106M063AC3AA Electrolytic Capacitor Specifications:
- Capacitance: 10 uF
- Capacitance Tolerance: 20%
- Voltage DC: 63 VDC, 79 VDC (Surge)
- Temperature Range: -40°C to +105°C
- Rated Temperature: 105°C
- Life: 2000 Hrs
- Dissipation Factor: 10% at 120Hz 25°C
- Ripple Current: 55 mA at 120Hz 105°C
- Leakage Current: 6.3 μA at 20°C for 2 min
- Impedance Ratio at -25°C: 2
- Impedance Ratio at -40°C: 3
- Dimensions: Diameter 5mm ±0.5mm, Length 11mm +1.5mm, Lead Spacing 2mm ±0.5mm
- Material: Aluminum Electrolytic
- Terminals: Wire Leads
- Certification: RoHS Compliant
- Packaging: Bulk, Bag, Quantity: 10,000
Buy the Buy YAGEO ESH Series Capacitor Part Number ESH106M063AC3AA Online
Enhance your electronic projects with the YAGEO ESH Series aluminum electrolytic capacitor, featuring 10 microfarads capacitance, 63V rated voltage, and operating temperature range from -40°C to +105°C. Designed for decoupling, filtering, and bypass applications, this high CV, reliable component offers a lifespan of 2,000 hours. Equipped with wire leads and a safety vent, it ensures secure installation and safe operation. Purchase online today to experience superior performance in your high-demand electronic applications, backed by quality standards and trusted manufacturer support.
Order your YAGEO ESH106M063AC3AA aluminum electrolytic capacitor today and ensure reliable decoupling and filtering for your high-reliability projects.
Frequently Asked Questions
Where can I buy KEMET ESH106M063AC3AA?
You can click on the BUY or RFQ button to purchase ESH106M063AC3AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ESH106M063AC3AA?
You can download the ESH106M063AC3AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ESH106M063AC3AA?
KEMET
