KEMET ESH107M200AM7AA Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor offers 100 uF capacitance with a 20% tolerance, rated at 200 VDC and operating in temperatures from -25°C to +105°C. It features wire leads, a compact size with a diameter of 16mm, length of 25mm, and lead spacing of 7.5mm. Designed for high CV applications, it provides a life expectancy of 2000 hours, with a dissipation factor of 15% at 120Hz and 25°C, and a ripple current of 350 mA. Suitable for various electronic circuits requiring reliable, high-voltage filtering and energy storage.
KEMET ESH107M200AM7AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 100 uF
- Capacitance Tolerance: 20%
- Voltage DC: 200 VDC, 250 VDC (Surge)
- Temperature Range: -25°C to +105°C
- Rated Temperature: 105°C
- Life: 2000 Hours
- Dissipation Factor: 15% at 120Hz, 25°C
- Ripple Current: 350 mA at 120Hz, 105°C
- Leakage Current: 610 uA at 20°C for 2 minutes
- Impedance Ratio at -25°C: 4
- Dimensions: Diameter 16mm ±0.5mm, Length 25mm +2.0/-0mm
- Lead Spacing: 7.5mm ±0.5mm
- Lead Type: Wire Leads
- Packaging: Bulk, Bag
- Packaging Quantity: 1000 units
Buy the KEMET Series ESH Aluminum Electrolytic Capacitor: ESH107M200AM7AA
Purchase the KEMET Series ESH aluminum electrolytic capacitor ESH107M200AM7AA online today and secure a high-quality component for your electronics. With a capacity of 100uF and a voltage rating of 200VDC, this capacitor is suitable for high-voltage filtering and energy storage. Its compact size, wire leads, and broad temperature range make it ideal for demanding applications. Trust in KEMET's proven durability and performance, and order now to keep your projects running smoothly and efficiently with this reliable, RoHS-compliant capacitor.
Order your KEMET Series ESH aluminum electrolytic capacitor ESH107M200AM7AA today and ensure reliable power stability for your electronic projects.
