KEMET ESK338M010AL3AA Aluminum Electrolytic Capacitor
The ESK aluminum electrolytic capacitor is designed for reliable performance in various electronic applications. Featuring a capacitance of 3,300 uF with a 20% tolerance, it operates at a voltage of 10 VDC and can surge up to 13 VDC. It withstands temperatures from -40°C to +85°C, with a rated temperature of 85°C, ensuring durability under thermal stress. Its compact dimensions include a diameter of 13mm, length of 20mm, and lead spacing of 5mm. Suitable for power supplies, filters, and electronic circuits, it offers high ripple current of 1250 mA at 120Hz and 85°C, with a life expectancy of 2000 hours.
KEMET ESK338M010AL3AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 3,300 uF
- Capacitance Tolerance: 20%
- Voltage DC: 10 VDC, Surge up to 13 VDC
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Life: 2000 Hrs
- Ripple Current: 1250 mA at 120Hz 85°C
- Leakage Current: 330 uA (2 min 20°C)
- Impedance Ratio at -25°C: 6
- Impedance Ratio at -40°C: 8
- Dimensions: Diameter 13mm ±0.5mm, Length 20mm +2mm, Lead Spacing 5mm ±0.5mm
Buy the KEMET ESK338M010AL3AA – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Experience reliable performance with the KEMET aluminum electrolytic capacitor. With a capacitance of 3,300 uF, operating at 10 VDC and a temperature range of -40°C to +85°C, it is ideal for power supply smoothing, filtering, and electronic circuits demanding high ripple current. Its compact size and robust construction ensure durability in demanding environments. Purchase online today and enhance your project with a high-quality component designed for longevity and stable operation, perfect for industrial, consumer, and automotive applications.
Get KEMET ESK338M010AL3AA today—built for precision and long-lasting durability in electronic circuits.
Frequently Asked Questions
Where can I buy KEMET ESK338M010AL3AA?
You can click on the BUY or RFQ button to purchase ESK338M010AL3AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ESK338M010AL3AA?
You can download the ESK338M010AL3AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ESK338M010AL3AA?
KEMET
