KEMET ESY477M016AG8AA Aluminum Electrolytic Capacitor
The KEMET ESY series aluminum electrolytic capacitor features a 470 microfarad capacitance with a 20% tolerance, rated for 16V DC with surge tolerance up to 20V. Operating from -40°C to +105°C, it has a low impedance design, measuring approximately 8mm in diameter with a 3.5mm lead spacing. Built with wire leads and RoHS compliant, it offers a low dissipation factor of 16% and a ripple current capacity of 1000mA at 105°C, making it ideal for high-temperature, low-impedance applications requiring reliability and long service life of 3000 hours.
KEMET ESY477M016AG8AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 470 uF
- Capacitance Tolerance: 20%
- Voltage DC: 16 V, Surge Voltage: 20 V
- Operating Temperature Range: -40°C to +105°C
- Dimensions: Diameter approximately 8mm, Lead Spacing 3.5mm
- Life Expectancy: 3000 hours at 105°C
- Dissipation Factor: 16.00%
- Equivalent Series Resistance: 0.056 Ohms at 100 kHz
- Ripple Current: 1000mA at 105°C, 100kHz
- Leakage Current: 75.2 μA at 20°C for 2 minutes
- Packaging: Bulk, Bag, Quantity: 5000
- RoHS Compliant: Yes
Buy the KEMET Series ESY Aluminum Electrolytic Capacitor: ESY477M016AG8AA
Enhance your electronic projects with the KEMET ESY series aluminum electrolytic capacitor, offering 470 microfarad capacitance, 16V DC rating, and reliable performance across -40°C to +105°C. Designed with wire leads and low impedance features, it ensures optimal operation in high-temperature environments. This component boasts a long lifespan of 3000 hours, low dissipation factor, and high ripple current capacity, making it ideal for power supply filtering, buffering, and other critical electronic functions. Bulk packaging ensures availability for large-scale manufacturing needs.
Buy KEMET ESY477M016AG8AA aluminum electrolytic capacitor now and experience high reliability and excellent performance in demanding electrical applications.
Frequently Asked Questions
Where can I buy KEMET ESY477M016AG8AA?
You can click on the BUY or RFQ button to purchase ESY477M016AG8AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ESY477M016AG8AA?
You can download the ESY477M016AG8AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ESY477M016AG8AA?
KEMET
