KEMET FLLD31K0APVI1 EMI Filter
The KEMET FLLD3-PV EMI filter is designed for high-performance noise suppression in three-phase systems. With a robust chassis mount style, it features threaded M12 studs, a rating of 520 VAC, and a rated current of 1000 A at 50°C. The filter dimensions are approximately 350x230x170mm, capable of operating within a temperature range of -40°C to +100°C. Compliant with IEC/EN 60939 and UL 1283 standards, it provides effective electromagnetic interference filtering for industrial and electrical infrastructure applications, ensuring reliable operation and compliance with safety regulations.
KEMET FLLD31K0APVI1 EMI Filter Specifications:
- Dimensions: 350x230x170 mm
- Rated Voltage AC: 520 VAC
- Rated Frequency: 50-60 Hz
- Rated Current: 1000 A (50°C)
- Nominal Temperature: 50°C
- Temperature Range: -40°C to +100°C
- Climate Category: 40/100/21
- Test Voltage DC (P to P): 2250 VDC
- Test Voltage DC (P to E): 3000 VDC
- Power Loss: 75 W (25°C, 50 Hz)
- Leakage Current: 5 mA (MAX)
- Terminal Type: Threaded Studs M12
- RoHS Compliant: Yes
- Standards: IEC/EN 60939, UL 1283
- Packaging: Bulk, Quantity: 1
- Weight: 17 kg
Buy the KEMET Series FLLD3-PV EMI Filter: FLLD31K0APVI1
Purchase the KEMET FLLD31K0APVI1 EMI filter online today and ensure superior noise suppression for your three-phase electrical systems. Designed for demanding industrial environments, this high-capacity filter offers 520 VAC voltage rating and 1000 A rated current, supporting reliable operation with minimal power loss. Its rugged chassis mount construction with threaded M12 studs guarantees secure installation. Operating efficiently between -40°C and +100°C, it complies with IEC/EN 60939 and UL 1283 standards, making it an essential component for industrial EMC compliance and electromagnetic interference reduction.
Buy KEMET FLLD31K0APVI1 now and experience unmatched reliability and noise suppression for industrial power systems.
Frequently Asked Questions
Where can I buy KEMET FLLD31K0APVI1?
You can click on the BUY or RFQ button to purchase FLLD31K0APVI1 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part FLLD31K0APVI1?
You can download the FLLD31K0APVI1 datasheet or visit the KEMET website for support.
Who is the manufacturer of FLLD31K0APVI1?
KEMET
