KEMET GL2030M Noise Filter
The KEMET GL-2030M noise filter is a metal box EMI/RFI suppression component designed for noise reduction in electrical circuits. Operating at 250 VAC with a rated current of 3 A, it features screw terminals for secure connections. This filter offers excellent noise suppression capabilities with a leakage current maximum of 0.5 mA at 250 V 60 Hz. Its compact dimensions are approximately 82 mm in length, 56 mm in width, and 38 mm in height, making it suitable for various electronic applications requiring effective electromagnetic interference filtering.
KEMET GL2030M Noise Filter Specifications:
- Voltage AC: 250 VAC
- Rated Current: 3 A (AC/DC)
- Rated Temperature: 55°C
- Temperature Range: -25/+55°C
- Leakage Current: 0.5 mA MAX (250 V 60 Hz)
- Resistance: 300 MOhms MIN Insulation 500 VDC 1 Min. Line To Ground
- Dimensions: Length approximately 82 mm, Width approximately 56 mm, Height approximately 38 mm
- Lead Terminals: Screw terminals
- Packaging: Tray or box, Quantity: 8 units, Weight: 200g
Buy the Buy KEMET EMI/RFI Filter Part Number GL-2030M Online
Purchase the KEMET GL-2030M noise filter online today and optimize your electronic systems for minimal electromagnetic interference. This high-quality noise suppression device is designed with metal box construction and screw terminals for secure connections. Operating efficiently at 250 VAC and rated for 3 A, it provides excellent noise reduction and insulation, making it ideal for sensitive circuit components. With compact dimensions and robust features, this filter ensures reliable performance and is suitable for various industrial and electronic applications demanding EMI/RFI noise suppression.
Buy KEMET GL-2030M noise suppression filter now and enjoy reliable noise filtering, high insulation, and secure screw terminals for your electronic applications.
Frequently Asked Questions
Where can I buy KEMET GL2030M?
You can click on the BUY or RFQ button to purchase GL2030M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part GL2030M?
You can download the GL2030M datasheet or visit the KEMET website for support.
Who is the manufacturer of GL2030M?
KEMET
