KEMET LDEED3220KA5N00 Film Capacitor
The KEMET LDEED3220KA5N00 is an automotive-grade metallized PEN stacked film capacitor designed for high-reliability applications. This SMD chip features a capacitance of 0.22 uF with a 10% tolerance, rated for 63 VAC and 100 VDC at a maximum temperature of 125°C. Its compact 2220 package size ensures efficient integration into automotive and electronic systems. Suitable for circuit filtering, decoupling, and energy storage, it complies with RoHS and AEC-Q200 standards, ensuring durability and performance in demanding environments.
KEMET LDEED3220KA5N00 Film Capacitor Specifications:
- Capacitance: 0.22 uF
- Capacitance Tolerance: 10%
- Voltage AC: 63 VAC
- Voltage DC: 100 VDC
- Temperature Range: -55/+125°C
- Rated Temperature: 125°C
- Dielectric: Metallized PEN Stacked
- Package Size: 2220
- Dimensions: Length 6mm ±0.3mm, Width 5mm ±0.4mm, Max height 2.4mm, Tape & Reel packaging with 3000 units
- Dissipation Factor: 0.8% at 1kHz
- Insulation Resistance: 1 GOhms
- Max dVdt: 100 V/us
- RoHS Compliant: Yes
- Qualification: AEC-Q200, MSL 3
- Component Weight: 0.267 g
Buy the KEMET Series LDE Film Capacitor: LDEED3220KA5N00
Purchase the KEMET LDEED3220KA5N00 film capacitor online today. Designed for automotive and industrial applications, this 0.22 uF, 63 VAC component offers excellent performance at high temperatures. Its compact 2220 package ensures easy integration into tight spaces. Built with high-quality metallized PEN dielectric, it provides high insulation resistance and low dissipation factor. Ideal for circuit filtering, decoupling, and energy storage, this capacitor meets RoHS and AEC-Q200 standards, guaranteeing long-term reliability in demanding environments.
Get KEMET LDEED3220KA5N00 today—engineered for high reliability and automotive-grade durability.
Frequently Asked Questions
Where can I buy KEMET LDEED3220KA5N00?
You can click on the BUY or RFQ button to purchase LDEED3220KA5N00 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part LDEED3220KA5N00?
You can download the LDEED3220KA5N00 datasheet or visit the KEMET website for support.
Who is the manufacturer of LDEED3220KA5N00?
KEMET
