KEMET LDEMG3220KA5N00 Film Capacitor
The LDEMG3220K A5NO0 is a high-quality film capacitor suitable for automotive and industrial applications. It features metallized PEN stacking dielectric, with a capacitance of 0.22 uF and a tolerance of 10%. Designed for versatile use, it supports operating voltages of 160 VAC and 400 VDC, with a maximum temperature rating of 125°C. The compact SMD chip measures approximately 13mm in length, 10.4mm in width, and 3.8mm in height, and complies with RoHS and AEC-Q200 standards, ensuring reliable performance and durability in demanding environments.
KEMET LDEMG3220KA5N00 Film Capacitor Specifications:
- Capacitance: 0.22 uF
- Capacitance Tolerance: 10%
- Voltage AC: 160 VAC
- Voltage DC: 400 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 125°C
- Dimensions: Length 13mm ±0.4mm, Width 10.4mm ±0.5mm, Height 3.8mm MAX
- Dielectric: Metallized PEN Stacked
- Features: Automotive Grade, RoHS Compliant, AEC-Q200 Qualified
- Insulation Resistance: 1 GOhms
- Dissipation Factor: 0.8% at 1kHz
- Packaging: Tape & Reel, Quantity: 1250
- Maximum dV/dt: 100 V/μs
- Component Weight: 1.2g
Buy the YAGEO Series LDE Film Capacitor: LDEMG3220K A5NO0
Enhance your electronic designs with the YAGEO Series LDEMG3220K A5NO0 film capacitor. With a capacitance of 0.22 uF, support for 160 VAC and 400 VDC, and a temperature rating of 125°C, it delivers high reliability. Its compact SMD design measures approximately 13mm by 10.4mm, making it ideal for space-constrained applications. Certified for automotive use and RoHS compliant, this capacitor ensures durability and excellent performance in harsh environments. Purchase online today for dependable quality.
Order your YAGEO Series LDEMG3220K A5NO0 automotive-grade film capacitor today and ensure reliable high-temperature performance for demanding electronic projects.
Frequently Asked Questions
Where can I buy KEMET LDEMG3220KA5N00?
You can click on the BUY or RFQ button to purchase LDEMG3220KA5N00 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part LDEMG3220KA5N00?
You can download the LDEMG3220KA5N00 datasheet or visit the KEMET website for support.
Who is the manufacturer of LDEMG3220KA5N00?
KEMET
