KEMET LDEQD1220KA5N00 Metallized PEN Film Capacitor
The LDE series metallized PEN stacked film capacitor is designed for automotive and industrial applications, offering high stability and reliability. It features a capacitance of 2200 pF with 10% tolerance, rated for 250 VAC and 1000 VDC with an operating temperature range from -55°C to +125°C. This surface-mount device (SMD) complies with RoHS standards and is qualified under the AEC-Q200 automotive grade. Its compact chip size includes dimensions of approximately 6mm in length, 5mm in width, and a stack height of 2mm, making it ideal for space-conscious designs requiring robust performance.
KEMET LDEQD1220KA5N00 Metallized PEN Film Capacitor Specifications:
- Capacitance: 2200 pF
- Capacitance Tolerance: 10%
- Voltage AC: 250 VAC
- Voltage DC: 1000 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 125°C
- Dimensions: Length 6mm +/-0.3mm, Width 5mm +/-0.4mm, Max Height 2mm
- Dissipation Factor: 0.8% at 1kHz
- Insulation Resistance: 1 GOhms
- Max dVidt: 300 V/us
- Chip Size: 2220
- RoHS Compliant, AEC-Q200 Qualified, Packaging: T&R, Quantity: 3000 pieces
Buy the KEMET Series LDE Film Capacitor: LDEQD1220KA5N00
Enhance your electronic designs with the high-quality KEMET Metallized PEN Film Capacitor, perfect for automotive and industrial use. Featuring 2200 pF capacitance, 250 VAC, 1000 VDC ratings, and operating from -55°C to +125°C, this compact SMD component ensures durability and stability. RoHS compliant and qualified under AEC-Q200 standards, it offers reliable performance in demanding environments. Purchase online today to benefit from quick delivery, competitive prices, and trusted KEMET quality for your critical projects.
Buy KEMET LDEQD1220KA5N00 now and experience unmatched reliability and performance for automotive and industrial applications.
Frequently Asked Questions
Where can I buy KEMET LDEQD1220KA5N00?
You can click on the BUY or RFQ button to purchase LDEQD1220KA5N00 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part LDEQD1220KA5N00?
You can download the LDEQD1220KA5N00 datasheet or visit the KEMET website for support.
Who is the manufacturer of LDEQD1220KA5N00?
KEMET
