KEMET MA2053 Noise Filter
The KEMET MA Series noise filter is designed for EMI/RFI noise suppression in electronic circuits. Capable of handling 250 VAC and 5 A, it features RoHS compliance, UL, CSA, and TUV certifications for safety and quality. The filter includes a plastic box housing, with dimensions of approximately 38 mm in length, 22.5 mm in height, and a minimum line-to-ground distance of 7 mm. Its resistance is 200 MOhms at 500 VDC, with a leakage current maximum of 0.75 mA at 250 V 60 Hz, suitable for reducing electromagnetic interference in sensitive electronic applications.
KEMET MA2053 Noise Filter Specifications:
- Voltage AC: 250 VAC
- Withstanding Voltage: 1500 VAC
- Rated Current: 5 A (AC/DC)
- Dimensions: Length 38 mm, Height 22.5 mm, Minimum line-to-ground 7 mm
- Resistance: 200 MOhms at 500 VDC
- Leakage Current: 0.75 mA MAX at 250 V 60 Hz
- Operating Temperature Range: -25°C to +55°C
- Housing Material: Plastic
- RoHS Compliant: Yes
- Certifications: UL, CSA, TUV
Buy the KEMET Series MA Noise Filter: MA2053
Order the KEMET MA2053 noise filter now and experience reliable EMI and RFI noise suppression suitable for sensitive electronic devices. Featuring a compact plastic housing, it handles 250 VAC and 5 A current, ensuring peak performance in various applications. Its RoHS compliance and safety certifications like UL, CSA, and TUV guarantee quality and safety. Perfect for reducing electromagnetic interference in industrial, consumer, or communication equipment. Purchase online today to enhance your device’s noise filtering capabilities with this durable, high-quality filter designed for long-lasting performance.
Get KEMET MA2053 noise filter today—designed for EMI/RFI noise suppression with robust safety certifications.
Frequently Asked Questions
Where can I buy KEMET MA2053?
You can click on the BUY or RFQ button to purchase MA2053 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part MA2053?
You can download the MA2053 datasheet or visit the KEMET website for support.
Who is the manufacturer of MA2053?
KEMET
