KEMET OHD3110M Thermal Reed Switch
The KEMET OHD thermal reed switch features radial tab leads, high temperature accuracy of 110°C, and high reliability suitable for industrial applications. It boasts a long operational life, excellent environmental durability, rapid response time, and a switching temperature tolerance of ±5°C. Designed for high-speed switching, it operates within a temperature range from -20°C to +150°C, with a maximum voltage of 110 VAC/DC and a current capacity of up to 0.3 Amps. Ideal for precise temperature sensing and control in demanding environments.
KEMET OHD3110M Thermal Reed Switch Specifications:
- Switching Temperature: 110°C ±5°C
- Temperature Range: -20°C to +150°C
- Contact Type: Make
- Lead Type: Radial Tab
- Dimensions: Length 27mm MAX, Height 6mm, Thickness 135mm
- Voltage DC: 2500 VAC/1 min, 3000 VAC/1 sec
- Voltage AC: 110 VAC MAX (Opening/Closing)
- Current: 0.3 Amps MAX (AC/DC)
- Resistance: 150 mOhms MAX
- Max Power: 6 W (AC/DC)
- Max Voltage: 110 V (AC/DC)
- Differential Temperature: 10°C
- RoHS & REACH Compliant, UL, CSA, TUV Certified
Buy the KEMET Series OHD Thermal Reed Switch: OHD3110M
Purchase the KEMET OHD thermal reed switch online today to ensure high reliability and durable environmental resistance for your industrial temperature sensing needs. With a maximum switching temperature of 110°C and a wide operating range from -20°C to +150°C, it offers rapid response and long operational life. Featuring radial tab leads, UL, CSA, and TUV certification, this switch guarantees safety, performance, and ease of installation. Order now for quick delivery and dependable performance in demanding industrial environments.
Get KEMET OHD thermal reed switch today—designed for high-temperature reliability and precise temperature sensing.
Frequently Asked Questions
Where can I buy KEMET OHD3110M?
You can click on the BUY or RFQ button to purchase OHD3110M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part OHD3110M?
You can download the OHD3110M datasheet or visit the KEMET website for support.
Who is the manufacturer of OHD3110M?
KEMET
