KEMET OHD5R105B Thermal Reed Switch
The KEMET OHD thermal reed switch is a high-reliability, high-speed response component designed for precise temperature sensing and switching applications. Featuring a radial mounting style, 105°C switching temperature, and excellent environmental durability, it operates reliably within a temperature range of -20°C to +150°C. This switch provides a plant-safe, long operational life with a break contact type, maximum voltage of 30 VDC, and a contact resistance of up to 300 mOhms. Suitable for various industrial and control systems requiring accurate thermal switching, it includes wire leads for easy integration.
KEMET OHD5R105B Thermal Reed Switch Specifications:
- Dimensions: Length 18.1mm, Height 5mm, Width 7mm
- Switching Temperature: 105°C ±5°C
- Temperature Range: -20°C to +150°C
- Contact Type: Break
- Maximum Voltage: 30 VDC
- Contact Resistance: 300 mOhms Max
- Max Power: 1 W (DC)
- Lead Style: Wire Leads
- Mounting: Radial
- Material: Thermal Reed Switch
- RoHS Compliant: Yes
- REACH Compliant: Yes
- Operating Life: Long operational life with high environmental durability
- Response Time: High-speed response
- Qualification Standards: UL, CSA, TUV
- Weight: 11 grams
Buy the Buy KEMET Thermal Reed Switch Part Number OHD5R105B Online
Get your KEMET thermal reed switch OHD5R105B now online to benefit from high reliability, excellent environmental durability, and precise temperature switching at 105°C. Designed for industrial applications, it features a break contact type, wire leads, and operates effectively over a wide temperature range of -20°C to +150°C. Its compact dimensions and UL, CSA, TUV certifications ensure safety and performance. Purchase this high-quality switch online today to enhance your control systems with dependable thermal switching performance.
Order your KEMET SeriesOHD thermal reed switch today and experience durable, high-temperature accuracy for reliable industrial controls.
Frequently Asked Questions
Where can I buy KEMET OHD5R105B?
You can click on the BUY or RFQ button to purchase OHD5R105B from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part OHD5R105B?
You can download the OHD5R105B datasheet or visit the KEMET website for support.
Who is the manufacturer of OHD5R105B?
KEMET
