KEMET OHD5R120B Thermal Reed Switch
The OHD series thermal reed switch from KEMET is a high-reliability, fast-response component suitable for various temperature sensing applications. Operating with a 120°C switching temperature and a tolerance of ±5°C, this radial switch features wire leads and long operational life. Designed for environmental durability, it withstands temperatures from -20°C to +150°C. With UL, CSA, and TUV certifications, it supports a maximum switching voltage of 30 VDC and current of 0.1 A, making it ideal for precise temperature control circuits.
KEMET OHD5R120B Thermal Reed Switch Specifications:
- Dimensions: Length 18.1mm, Height 5mm, Thickness 7mm
- Switching Temperature: 120°C ±5°C
- Temperature Range: -20°C to +150°C
- Contact Type: Break
- Voltage: Max 30 VDC
- Current: Max 0.1 Amps DC
- Voltage Rating: 1500 VAC /1 minute, 1800 VAC /1 second
- Resistance: 300 mOhms MAX
- Weight: 11g
- RoHS & REACH Compliant
- Mounting Type: Radial, Wire Leads
- Sensitivity Differential: 10°C MAX
Buy the KEMET Series OHD Thermal Reed Switch: OHD5R120B
Purchase the KEMET Series OHD Thermal Reed Switch OHD5R120B online today for dependable temperature control applications. Featuring high reliability, fast response, and environmental durability, this switch operates at 120°C with a tolerance of ±5°C. Its radial design with wire leads makes installation straightforward, while UL, CSA, and TUV certifications ensure safety and quality. Perfect for industrial temperature sensing, it supports up to 30 VDC and 0.1 A current, providing long-lasting performance and precise operation in demanding environments.
Order your KEMET Series OHD Thermal Reed Switch OHD5R120B today and ensure reliable, precise temperature sensing for your industrial and control projects.
