KEMET PEG124YH2220QL1 Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor PEG124YH2220QL1 features a 22 uF capacitance with a -10/+30% tolerance, rated at 450 VDC. It operates within a temperature range of -40°C to +105°C, providing long life and reliable performance for high-voltage applications. The axial lead style and RoHS compliance make it suitable for diverse electronic circuits. With a rated life of 22,000 hours and low leakage current, this capacitor ensures consistent durability and stability in demanding environments. Its compact dimensions facilitate easy integration into electronic assemblies.
KEMET PEG124YH2220QL1 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 22 uF
- Capacitance Tolerance: -10/+30%
- Voltage DC: 450 VDC
- Temperature Range: -40°C to +105°C
- Rated Temperature: 105°C
- Life: 22,000 hours
- Leakage Current: 30 uA (5 min, 20°C)
- Resistance: 2400 mOhms (100Hz 20°C), 1100 mOhms (10kHz 20°C)
- Ripple Current: 0.24 Amps (100Hz 105°C), 1.6 Amps (5kHz 60°C), 0.56 Amps (5kHz 105°C)
- Inductance: 12 nH (ESL)
- Dimensions: Diameter 20mm ±0.5mm, Length 29mm ±1mm, Lead bend dimensions specified per customer requirements
- RoHS compliant: Yes
- Shelf Life: 156 weeks
- Packaging: Bulk, Bag
Buy the YAGEO Series PEG124 Aluminum Electrolytic Capacitor: PEG124YH2220QL1
Purchase the YAGEO Series PEG124YH2220QL1 aluminum electrolytic capacitor online today and benefit from its robust 22 microfarad capacitance, 450VDC rating, and extended lifespan of 22,000 hours. This high-performance capacitor is designed for demanding applications with operating temperatures from -40°C to +105°C, offering excellent stability, low leakage current, and compliant with RoHS standards. Its axial leads simplify installation, making it ideal for high-voltage, high-reliability electronic projects. Trust in quality and get your order now!
Order your YAGEO Series PEG124YH2220QL1 aluminum electrolytic capacitor today and ensure reliable, long-lasting performance in high-voltage circuits.
Frequently Asked Questions
Where can I buy KEMET PEG124YH2220QL1?
You can click on the BUY or RFQ button to purchase PEG124YH2220QL1 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PEG124YH2220QL1?
You can download the PEG124YH2220QL1 datasheet or visit the KEMET website for support.
Who is the manufacturer of PEG124YH2220QL1?
KEMET
