KEMET PEH532VDE3470M2 Aluminum Electrolytic Capacitors
The PEH532 series are snap-in aluminum electrolytic capacitors rated for +105°C with high ripple current capability, low ESR, and long operational life. Designed for power supply, inverter, welding, and UPS applications, these capacitors feature low leakage current, robust construction, and are suitable for high-reliability environments. They are designed with etched aluminum foil, electrolyte impregnation, and quality aging processes to ensure durability. Ideal for compact, high-current electronic circuits, they are mounted via thermal and mounting terminals in any position for flexible installation.
KEMET PEH532VDE3470M2 Aluminum Electrolytic Capacitors Specifications:
- Capacitance Range: 68 - 27,000 pF
- Rated Voltage: 35 ~ 450 VDC
- Operating Temperature: -40 to +105°C
- Capacitance Tolerance: ±20% at 100 Hz / +20°C
- Lifetime: 1,500 to 2,000 hours at +105°C
- Leakage Current: ≤ 0.003 CV (μA)
- Vibration Resistance: 0.75 mm displacement or 10 g, 3 × 2-hour cycles
- Endurance: 2,000 hours at +105°C with specified ripple current
- Physical Size: D and L dimensions vary with case and capacitance, typically in the range of 22x25 mm to 35×50 mm
- Construction: Etched aluminum foil, electrolyte, paper separator, sealed in aluminum can with safety vent
- Mounting: Snap-in with terminals suitable for any position, insulation sleeve included
- Certifications: UL recognized (UL No. E358957), RoHS compliant
Buy the KEMET Series PEH532 Aluminum Electrolytic Capacitors: 35-450 VDC
Purchase the KEMET PEH532 aluminum electrolytic capacitors online today for reliable, high-performance power supply solutions. Designed to operate at +105°C with high ripple current capacity, low ESR, and long operational lifetime, these capacitors are ideal for applications requiring durable, compact, and efficient power electronic components. Whether for UPS, inverter drives, or welding equipment, our easy online ordering ensures fast delivery. Invest now for superior quality, robustness, and peace of mind in your electronic designs.
Buy KEMET PEH532 long-life aluminum electrolytic capacitors now and experience unmatched reliability, advanced high ripple current capability, and low ESR for power electronics.
Frequently Asked Questions
Where can I buy KEMET PEH532VDE3470M2?
You can click on the BUY or RFQ button to purchase PEH532VDE3470M2 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PEH532VDE3470M2?
You can download the PEH532VDE3470M2 datasheet or visit the KEMET website for support.
Who is the manufacturer of PEH532VDE3470M2?
KEMET
