KEMET PEH534PAB3470M2 Electronic Capacitor
This electronic component is a capacitor with a capacitance of 470 microfarads, rated for 100VDC voltage operation. It features a compact size with a diameter of 22.5mm and a length of 26mm, equipped with two snap-in terminals for easy installation. Designed to operate efficiently from -40°C to 105°C, it exhibits low ESR—344 milliohms at 100 Hz and 254 milliohms at 100 kHz—and allows a ripple current of 1A rms at 100Hz. Suitable for power supply filters, energy storage, and electronic circuits requiring reliable capacitance and thermal stability.
KEMET PEH534PAB3470M2 Electronic Capacitor Specifications:
- Capacitance: 470μF
- Rated Voltage: 100VDC
- Lower Cap Tolerance: 20%
- Upper Cap Tolerance: 20%
- Diameter: 22.5mm ±0.5mm
- Length: 26mm ±1mm
- Terminals: 2 Pin Snap-in
- ESR: 344 milliohms max at 100 Hz, 20°C
- ESR: 254 milliohms max at 100 kHz, 20°C
- Leakage Current: 0.141mA max at Test Voltage
- Temperature Range: -40°C to 105°C
- Surge Test Voltage: 115VDC
- Working Voltage: 100VDC
- Ripple Current: 1A rms at 100Hz and 105°C
Buy the KEMET 6.341 U– Reliable Capacitor for Industrial Applications
Enhance your electronic projects with this high-quality 470 microfarad, 100VDC capacitor featuring a compact design, low ESR, and broad temperature operation. Its 22.5mm diameter and 26mm length, along with snap-in terminals, ensure easy installation and durability. Ideal for power supplies, energy storage, and industrial electronics, it guarantees stable performance in demanding conditions. Purchase online now to benefit from fast delivery, competitive pricing, and trusted quality for your electrical and electronic applications.
Buy KEMET 6.341 now and experience unmatched reliability and performance in power supply and electronic circuits.
Frequently Asked Questions
Where can I buy KEMET PEH534PAB3470M2?
You can click on the BUY or RFQ button to purchase PEH534PAB3470M2 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PEH534PAB3470M2?
You can download the PEH534PAB3470M2 datasheet or visit the KEMET website for support.
Who is the manufacturer of PEH534PAB3470M2?
KEMET
