KEMET PHE426HF7220JR06L2 Polypropylene Film Capacitor
The PHE426/F426 series is a high-quality metallized polypropylene film capacitor suitable for general-purpose applications. Featuring a capacitance of 2.2 microfarads with a 5% tolerance, it operates at 250 VDC and is rated for a maximum temperature of 85°C. With radial wire leads, this capacitor offers reliable pulse performance and low dissipation factor, making it ideal for filtering, coupling, and bypass applications. Its compact dimensions include a length of 31.5mm, height of 20.5mm, and a lead spacing of 27.5mm, ensuring easy integration into various electronic circuits.
KEMET PHE426HF7220JR06L2 Polypropylene Film Capacitor Specifications:
- Capacitance: 2.2 uF
- Capacitance Tolerance: 5%
- Voltage DC: 250 VDC
- Operating Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Dissipation Factor: 0.1% 1kHz
- Insulation Resistance: 13.6364 GOhms
- Maximum dVidt: 50 Vius
- Inductance: 6 nH
- Dimensions: Length 31.5mm MAX, Height 20.5mm MAX, Thickness 10.5mm MAX, Lead Spacing 27.5mm ±0.4mm, Lead Length 6mm NOM, Lead Diameter 0.8mm NOM
Buy the Buy KEMET Capacitor Part Number PHE426HF7220JR06L2 Online
Discover the reliability of the KEMET Polypropylene Film Capacitor, designed for industrial and electronic applications. With a capacitance of 2.2 microfarads, 250 VDC voltage rating, and an operating temperature up to 85°C, this capacitor ensures optimal performance for filtering, coupling, and pulse applications. Compact and robust, it features radial wire leads, low dissipation factor, and high insulation resistance, making it suitable for demanding environments. Purchase online today to enhance your circuit's stability and efficiency with proven reliability.
Get KEMET PHE426HF7220JR06L2 today—built for reliable performance and long-lasting durability in electronic circuits.
Frequently Asked Questions
Where can I buy KEMET PHE426HF7220JR06L2?
You can click on the BUY or RFQ button to purchase PHE426HF7220JR06L2 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PHE426HF7220JR06L2?
You can download the PHE426HF7220JR06L2 datasheet or visit the KEMET website for support.
Who is the manufacturer of PHE426HF7220JR06L2?
KEMET
