KEMET PYR751147 Voltage Balancing Resistor
The PYR 7511 resistor is a wire-wound accessory designed for voltage balancing and capacitor discharge applications. Crafted with stainless steel and connected via high-temperature silicone coatings, it fits capacitor diameters ranging from 75-90 mm. The resistor features resistance values between 10 and 47 kΩ, with a tolerance of ±5% and a rated voltage of 700 VDC. Suitable for temperatures -55°C to +105°C, it offers easy mounting with adjustable brackets, ensuring reliability in series-connected electrolytic capacitor systems for discharge and voltage balancing. Compliant with CECC 40201 and MIL specifications.
KEMET PYR751147 Voltage Balancing Resistor Specifications:
- Resistance range 10-47 kΩ
- Resistance tolerance ±5%
- Rated voltage 700 VDC
- Temperature range -55°C to +105°C
- Fits capacitor diameters 75-90 mm
- Material: Stainless steel wire wound with ceramic core
- Coated with high-temperature silicone
- Standards: CECC 40201, MIL-R26E
- Dimensions vary based on model, adjustable brackets for mounting
- Resistance value options include 10, 18, 27, 47 kΩ
- Suitable for voltage balancing and discharge of electrolytic capacitors
- Easy to install with adjustable mounting brackets
Buy the Buy United Resistors PYR 7511 Part Number PYR751147 Online
Enhance your electronic systems with the United Resistors PYR 7511 voltage balancing resistor, crafted for reliable discharge and balancing of electrolytic capacitors. Designed with stainless steel wire wound on a ceramic core and coated for high temperature resilience, it fits capacitors with diameters from 75 to 90 mm. The resistor offers resistance values from 10 to 47 kΩ, rated at 700 VDC, and supports temperatures from -55°C to +105°C. Easy to install with adjustable brackets, ensuring durability, precision, and safety for demanding electronic applications.
Buy United Resistors PYR 7511 now and experience unmatched reliability and performance for voltage balancing and capacitor discharge.
Frequently Asked Questions
Where can I buy KEMET PYR751147?
You can click on the BUY or RFQ button to purchase PYR751147 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PYR751147?
You can download the PYR751147 datasheet or visit the KEMET website for support.
Who is the manufacturer of PYR751147?
KEMET
