KEMET R463I2680JHH1M Filament Capacitor
The R46 series metallized polypropylene film capacitor is designed for safety and EMI filtering applications. Rated for 310 VAC and 125°C, it features a 0.068 uF capacitance with a tolerance of 20%. Its radial style with lead spacing of 15mm ensures reliable performance in various electronic circuits. Suitable for use in industrial, automotive, and consumer electronics, it offers high insulation resistance, low dissipation factor, and compliance with RoHS standards. Its robust construction and safety features make it ideal for demanding electrical environments.
KEMET R463I2680JHH1M Filament Capacitor Specifications:
- Capacitance: 0.068 uF
- Capacitance Tolerance: 20%
- Voltage AC: 310 VAC (x2)
- Voltage DC: 630 VDC
- Temperature Range: -40°C to +125°C
- Rated Temperature: 125°C
- Dimensions: Length 18mm +0.3/-0.5mm, Height 40.1mm-0.5mm, Thickness 5mm +0.2/-0.5mm, Lead Spacing 15mm +/-0.4mm
- Dissipation Factor: 0.3% at 1kHz
- Insulation Resistance: 100 GOhms
- Max dVidt: 400 V/us
- Pack Quantity: 2000
- Features: EMI Safety, RoHS compliant
- Dielectric: Metallized Polypropylene
- Style: Radial
- Safety Class: X2
- Certification: ENEC, UL, cUL, CQC
- Lead Type: Cut leads
Buy the KEMET Series R46 310 VAC Capacitor: R46312680JHH1M
Secure your electronic projects with the KEMET R46312680JHH1M capacitor, featuring 310 VAC rating and 125°C temperature tolerance. Its metallized polypropylene dielectric ensures excellent electrical performance and safety. Designed for reliable EMI filtering and safety-critical applications, this radial capacitor offers 0.068 uF capacitance with a 20% tolerance, high insulation resistance, and RoHS compliance. Built to withstand demanding environments, it is an essential component for industrial, automotive, and consumer electronics, providing durable performance and peace of mind for your electronic systems.
Buy KEMET R46312680JHH1M now and experience unmatched reliability and performance in safety and EMI filtering applications.
Frequently Asked Questions
Where can I buy KEMET R463I2680JHH1M?
You can click on the BUY or RFQ button to purchase R463I2680JHH1M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R463I2680JHH1M?
You can download the R463I2680JHH1M datasheet or visit the KEMET website for support.
Who is the manufacturer of R463I2680JHH1M?
KEMET
