KEMET R463I315000H1M Film Capacitor
The R46 series capacitor is a safety-rated film capacitor made with metallized polypropylene dielectric, designed for EMI safety. It features a radial style with 15mm lead spacing, rated for 310 VAC in AC applications and 630 VDC, with a capacitance of 0.15 uF ±20%. Temperatures range from -40°C to +125°C, making it suitable for harsh environments. The capacitor complies with RoHS standards, weighs 2.1 grams, and is packaged in bulk, ideal for applications requiring high reliability and safety. It is UL, ENEC, cUL, and CQC qualified.
KEMET R463I315000H1M Film Capacitor Specifications:
- Capacitance: 0.15 uF
- Capacitance Tolerance: 20%
- Voltage AC: 310 VAC (X2)
- Voltage DC: 630 VDC
- Rated Temperature: 125°C
- Temperature Range: -40°C to +125°C
- Dielectric: Metallized Polypropylene
- Style: Radial
- Lead Spacing: 15mm ±0.4mm
- Dimensions: Length 18mm +0.3/-0.5mm, Height 12mm +0.1/-0.5mm, Thickness 6mm +0.2/-0.5mm
- Dissipation Factor: 0.3% at 1kHz
- Insulation Resistance: 100 GOhms
- Packaging: Bulk, Bag
- Weight: 2.1g
- Safety Standards: UL, ENEC, cUL, CQC
- RoHS Compliant
- Max dV/dt: 400 V/μs
Buy the Buy KEMET R46 310 VAC 125C Part Number R463I315000H1M Online
Order the KEMET R463I315000H1M film capacitor online today and experience high safety standards with metallized polypropylene dielectric. This capacitor offers 0.15 uF capacitance, 310VAC, 630VDC ratings, and is suitable for demanding environments with temperatures up to 125°C. Its radial design ensures easy installation, while RoHS compliance guarantees environmental safety. Perfect for EMI filtering and safety applications, this capacitor is packaged in bulk for high-volume needs, providing reliability and performance for industrial and electronic equipment.
Get KEMET R463I315000H1M today—built for safety and long-lasting reliability in demanding electronic applications.
Frequently Asked Questions
Where can I buy KEMET R463I315000H1M?
You can click on the BUY or RFQ button to purchase R463I315000H1M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R463I315000H1M?
You can download the R463I315000H1M datasheet or visit the KEMET website for support.
Who is the manufacturer of R463I315000H1M?
KEMET
