KEMET R463I322000L2M Safety Film Capacitor
The R46 series safety film capacitor features metallized polypropylene dielectric with a capacitance of 0.22 uF and a voltage rating of 310 VAC (X2) and 630 VDC. Designed for EMI safety and reliable performance, it operates within a temperature range of -40°C to +110°C. With radial lead configuration, safety certifications including UL, cUL, ENEC, and CQC, and a compact size, this capacitor is suitable for applications requiring high dielectric strength and safety standards. Its robust construction ensures stability and longevity in electrical circuits.
KEMET R463I322000L2M Safety Film Capacitor Specifications:
- Capacitance: 0.22 uF
- Capacitance Tolerance: 20%
- Voltage AC: 310 VAC (X2)
- Voltage DC: 630 VDC
- Temperature Range: -40°C to +110°C
- Rated Temperature: 110°C
- Dimensions: Length 18mm ±0.5mm, Height 125mm +0.1/-0.5mm, Thickness 9mm +0.2/-0.5mm
- Lead Spacing: 15mm ±0.4mm
- Dissipation Factor: 0.1% at 1kHz
- Insulation Resistance: 100 GOhms
- Maximum dV/dt: 400 V/us
- Material: Metallized polypropylene
- Features: EMI safety, RoHS compliant
- Weight: 2.542 g
- Packaging: Bulk, Bag; Quantity: 1000
Buy the KEMET Series R46 310 VAC Safety Capacitor: R4631322000L2M
Discover the reliable KEMET Series R46 safety film capacitor, featuring 0.22 uF capacitance, 310 VAC rating, and metallized polypropylene dielectric. Designed for high-voltage applications, it provides excellent EMI safety with UL, cUL, ENEC, and CQC certifications. Its robust construction ensures durability, stability, and long-term performance in demanding environments. Ideal for electronic circuits requiring safety, high dielectric strength, and compliance standards, this capacitor is available for quick and easy online purchase, helping you meet project deadlines efficiently.
Order your KEMET Series R46 310 VAC safety capacitor today and ensure high-quality, reliable performance for your electrical projects.
Frequently Asked Questions
Where can I buy KEMET R463I322000L2M?
You can click on the BUY or RFQ button to purchase R463I322000L2M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R463I322000L2M?
You can download the R463I322000L2M datasheet or visit the KEMET website for support.
Who is the manufacturer of R463I322000L2M?
KEMET
