KEMET R463I347040N0M Safety Film Capacitor
The R46 series safety film capacitor is designed for EMI filtering and safety applications, made with metallized polypropylene dielectric. It handles voltage up to 310 VAC (X2) and 630 VDC, with a capacitance of 0.47 uF and 20% tolerance. Its radial H style with wire leads measures approximately 18mm in length, 16mm in height, and 10mm in thickness. Operating within -40/+110°C, it features excellent dissipation factor (0.1% at 1kHz), insulation resistance of 63.8 GOhms, and is RoHS compliant, suitable for industrial and electronic equipment.
KEMET R463I347040N0M Safety Film Capacitor Specifications:
- Capacitance: 0.47 uF
- Capacitance Tolerance: 20%
- Voltage AC: 310 VAC (X2)
- Voltage DC: 630 VDC
- Operating Temperature Range: -40/+110°C
- Rated Temperature: 110°C
- Dimensions: Length 18mm +/-0.5mm, Height 16mm +0.1/-0.5mm, Thickness 10mm +0.2/-0.5mm
- Lead Spacing: 15mm +/-0.4mm
- Dissipation Factor: 0.1% at 1kHz
- Insulation Resistance: 63.8 GOhms
- Maximum dV/dt: 400 V/us
- Features: EMI Safety
- RoHS: Yes
Buy the KEMET Series R46 EMI Safety Film Capacitor: R4631347040NOM
Purchase the KEMET R4631347040NOM safety film capacitor online today. Designed for EMI filtering with metallized polypropylene dielectric, it handles up to 310 VAC and 630 VDC, offering reliable performance for industrial and electronic equipment. Compact and RoHS compliant, it features 0.47 uF capacitance, 20% tolerance, and operates from -40°C to 110°C, ensuring safety and durability. Perfect for applications requiring high insulation resistance and excellent dissipation characteristics. Buy now for quality and performance.
Get KEMET R4631347040NOM today—built for EMI safety and long-lasting durability in industrial and electronic applications.
