KEMET R463N322000M1M Safety Capacitor
This radial metallized polypropylene film capacitor offers 310 VAC (X2 safety), 630 VDC voltage ratings, and a capacitance of 0.22 uF with 20% tolerance. Designed for EMI safety and reliable performance in industrial applications, it features a temperature range of -40°C to +110°C, low dissipation factor of 0.1% at 1kHz, and insulation resistance of 100 GOhms. Its compact dimensions include a length of 26.5mm, height of 15mm, and lead spacing of 22.5mm, making it suitable for power and safety filtering in various electronic devices.
KEMET R463N322000M1M Safety Capacitor Specifications:
- Capacitance: 0.22 uF
- Capacitance Tolerance: 20%
- Voltage AC: 310 VAC (X2)
- Voltage DC: 630 VDC
- Temperature Range: -40°C to +110°C
- Rated Temperature: 110°C
- Dissipation Factor: 0.1% at 1kHz
- Insulation Resistance: 100 GOhms
- Dimensions: Length 26.5mm +0.3/-0.5mm, Height 15mm +0.1/-0.5mm, Thickness 6mm +0.2/-0.5mm, Lead Spacing 22.5mm +/-0.4mm
- Lead: Cut
- Features: EMI Safety
- Safety Class: X2
- RoHS Compliant: Yes
- Qualification: ENEC, UL, cUL, CQC
- Component Weight: 3.32 grams
Buy the KEMET R463N322000M1M – Reliable EMI Safety Capacitor for Industrial Applications
Purchase the KEMET R463N322000M1M safety capacitor online today and secure a high-quality component designed for industrial use. This metallized polypropylene film capacitor offers excellent EMI safety features, robust voltage ratings of 310 VAC and 630 VDC, and a wide temperature range from -40°C to +110°C. Its compact radial design with precise dimensions ensures easy installation in power supplies, filtering systems, and safety-critical applications. Rely on this RoHS-compliant capacitor for consistent, reliable performance in demanding environments. Order now and enhance your project’s safety and efficiency.
Order your KEMET Series R463N322000M1M safety capacitor today and ensure dependable performance in your industrial and power filtering projects.
