KEMET R463N347000N0K Safety Film Capacitor
The R46 310 VAC safety film capacitor by KEMET features metallized polypropylene dielectric, suitable for EMI safety applications. It supports 0.47 microfarads capacitance with 10% tolerance, rated at 310 VAC (X2) and 630 VDC, operating over -40°C to +110°C. Designed with radial style, lead spacing of 22.5mm, and certified with ENEC, UL, cUL, and CQC, it offers reliable insulation resistance and dissipation factor for demanding electrical environments. This capacitor is ideal for applications requiring robust electrical safety and high performance.
KEMET R463N347000N0K Safety Film Capacitor Specifications:
- Capacitance: 0.47 uF
- Capacitance Tolerance: 10%
- Voltage AC: 310 VAC (X2)
- Voltage DC: 630 VDC
- Temperature Range: -40°C to +110°C
- Rated Temperature: 110°C
- Dissipation Factor: 0.1% at 1kHz
- Insulation Resistance: 63.83 GOhms
- Lead Spacing: 22.5mm
- Dimensions: Length 26.5mm +0.3/-0.5mm, Height 16mm +0.1/-0.5mm, Thickness 7mm +0.2/-0.5mm
- Packaging: Bulk, Bag
- Packaging Quantity: 700
Buy the KEMET Series R46 310 VAC Safety Capacitor: R463N347000NOK
Enhance your electrical safety with the reliable KEMET Series R46 safety film capacitor. With metallized polypropylene dielectric, 0.47 microfarads capacitance, and rated at 310 VAC and 630 VDC, it offers excellent insulation resistance and safety certification. Its radial style, lead spacing of 22.5mm, and operating temperature range of -40°C to +110°C make it suitable for demanding applications. Trust in KEMET's quality to provide long-lasting performance in your electrical assemblies—order online today for fast, secure delivery.
Order your KEMET Series R46 310 VAC safety capacitor today and ensure reliable electrical safety for your demanding projects.
Frequently Asked Questions
Where can I buy KEMET R463N347000N0K?
You can click on the BUY or RFQ button to purchase R463N347000N0K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R463N347000N0K?
You can download the R463N347000N0K datasheet or visit the KEMET website for support.
Who is the manufacturer of R463N347000N0K?
KEMET
