KEMET R463N3680CKH1M High-Voltage Film Capacitor
The R463N3680CKH1M is a high-quality metallized polypropylene film capacitor designed for safety and EMI filtering applications. It features a capacitance of 0.68 uF with a 20% tolerance, rated at 310 VAC (X2) and 630 VDC, with a maximum operating temperature of 125°C. Its compact dimensions include a lead spacing of 22.5mm, making it suitable for various electronic circuits requiring reliable high-voltage performance. Certified for safety standards, this capacitor offers excellent insulation resistance and low dissipation factor, ideal for industrial and consumer electronics where safety and durability are critical.
KEMET R463N3680CKH1M High-Voltage Film Capacitor Specifications:
- Capacitance: 0.68 uF
- Capacitance Tolerance: 20%
- Voltage AC: 310 VAC (X2)
- Voltage DC: 630 VDC
- Rated Temperature: 125°C
- Maximum Operating Temperature: -40/+125°C
- Dielectric: Metallized Polypropylene
- Lead Spacing: 22.5mm ±0.4mm
- Dimensions: Length 26.5mm +0.3/-0.5mm, Height 20mm +0.1/-0.5mm, Thickness 11mm +0.2/-0.5mm
- Dissipation Factor: 0.2% at 1KHz
- Insulation Resistance: 44.1176 GOhms
- Packaging: T&R, Large, Quantity: 350
- Safety Class: X2
- Certifications: ENEC, UL, cUL, CQC
Buy the Buy KEMET R463N3680CKH1M Part Number R463N3680CKH1M Online
Purchase the KEMET R463N3680CKH1M film capacitor online today—engineered for safety, reliability, and excellent performance in high-voltage applications. This capacitor offers a capacitance of 0.68 uF with a 20% tolerance, rated at 310 VAC (X2) and 630 VDC, suitable for industrial electronics, filtering, and safety circuits. Its compact size with a lead spacing of 22.5mm ensures easy installation. Certified for safety standards including UL, ENEC, and cUL, it guarantees durability and consistent electrical performance across various demanding environments. Order now and enhance your electronic projects with reliable capacitor performance.
Get KEMET R463N3680CKH1M today—designed for high-voltage safety and long-lasting performance in electronic and industrial applications.
Frequently Asked Questions
Where can I buy KEMET R463N3680CKH1M?
You can click on the BUY or RFQ button to purchase R463N3680CKH1M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R463N3680CKH1M?
You can download the R463N3680CKH1M datasheet or visit the KEMET website for support.
Who is the manufacturer of R463N3680CKH1M?
KEMET
