KEMET R46KI22200001M Safety Film Capacitor
The R46 series safety Film Capacitor from KEMET is designed for EMI filtering and safety applications. It features metallized polypropylene dielectric, safety-certified (X2), rated at 275 VAC (AC), 560 VDC, with a capacitance of 0.022 µF and a tolerance of ±20%. Suitable for use in various demanding environments, it operates within a temperature range of -40°C to +110°C. Its radial lead style with a lead spacing of 15mm ensures easy mounting, while RoHS compliance guarantees environmentally friendly manufacturing. Ideal for filtered power supplies and noise suppression in electronic equipment.
KEMET R46KI22200001M Safety Film Capacitor Specifications:
- Capacitance: 0.022 uF
- Capacitance Tolerance: ±20%
- Voltage AC: 275 VAC (X2)
- Voltage DC: 560 VDC
- Operating Temperature Range: -40°C to +110°C
- Dielectric: Metallized Polypropylene
- Lead Spacing: 15mm
- Lead Style: Radial
- Dimensions: Length 18mm +0.3/-0.5mm, Height 11mm +0.1/-0.5mm, Thickness 5mm +0.2/-0.5mm
- RoHS Compliant: Yes
- Dissipation Factor: 0.1% at 1kHz
- Insulation Resistance: 100 GOhms
- Maximum Voltage Change Rate: 400 V/μs
Buy the KEMET Series R46 Safety Capacitor: R46KI22200001M
Purchase the KEMET R46 series safety film capacitor online today to ensure excellent EMI filtering and safety in your electronic circuits. With a capacitance of 0.022 microfarads and rated at 275 volts AC, this metallized polypropylene capacitor is RoHS compliant and ideal for power supply filtering, noise suppression, and safety applications. Its radial style with precise dimensions makes it easy to install in various enclosures, ensuring reliable operation across a temperature range of -40°C to +110°C. Promote your electronic projects with quality components from a trusted supplier.
Buy KEMET R46KI22200001M safety film capacitor now and experience unmatched reliability and noise suppression performance in your electronic applications.
