KEMET R75MI315050H3J Automotive Film Capacitor
The R75H Series by KEMET features metallized polypropylene film capacitors designed for automotive and pulse applications. These radial-lead components offer a capacitance of 0.15 microfarads with a tolerance of ±5%, rated voltage of 400 VDC, and a maximum operating temperature of 105°C. Constructed with RoHS compliance and AEC-Q200 qualification, they are suitable for automotive environments demanding high reliability. The compact design measures approximately 18mm in length with 15mm lead spacing, ensuring robust performance in demanding electrical circuits.
KEMET R75MI315050H3J Automotive Film Capacitor Specifications:
- Series: R75H
- Dielectric: Metallized Polypropylene
- Type: Radial
- Features: Automotive Grade, Pulse
- RoHS: Yes
- Lead: Wire Leads
- Qualification: AEC-Q200
- Component Weight: 1.8g
- Dimensions: Length 18mm +0.3/-0.5mm, Lead Spacing 15mm
- Capacitance: 0.15 uF
- Capacitance Tolerance: ±5%
- Rated Voltage DC: 400 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dissipation Factor: 0.05% at 1kHz, 0.08% at 10kHz
- Insulation Resistance: 100 GOhms
- Maximum dV/dt: 900 V/us
- Resistance: 10.61 mOhms (at 100kHz)
- Ripple Current: 900mA, 135mA
- Inductance: 10nH
Buy the Buy KEMET Automotive Capacitor Part Number R75MI315050H3J Online
Secure your automotive and pulse circuit needs with the KEMET R75H series metallized polypropylene film capacitors. These high-quality radial components feature 0.15 microfarads capacitance, rated for 400 volts DC, and operate reliably up to 105°C. Designed with automotive grade standards and RoHS compliance, they deliver exceptional performance in demanding environments. Ideal for pulse applications, these capacitors are compact, durable, and easy to integrate, ensuring your electronic systems function efficiently and reliably in any automotive or industrial setting.
Buy KEMET R75MI315050H3J now and experience unmatched reliability and performance in automotive applications.
Frequently Asked Questions
Where can I buy KEMET R75MI315050H3J?
You can click on the BUY or RFQ button to purchase R75MI315050H3J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75MI315050H3J?
You can download the R75MI315050H3J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75MI315050H3J?
KEMET
