KEMET R75MW468050H2J Automotive Film Capacitor
The R75MW468050H2J is an automotive-grade, metallized polypropylene film capacitor, offering 6.8uF capacitance at 400VDC and 105°C temperature rating. It features wire leads with an axial radial style and is designed for pulse applications in automotive environments. The capacitor provides excellent insulation resistance of 4.4 GOhms, low dissipation factor of 0.1% at 1kHz, and low inductance of 20 nH. Its dimensions are approximately 41.5mm length and 40mm height. RoHS compliant and qualified under AEC-Q200 standards, it ensures reliable performance in demanding conditions.
KEMET R75MW468050H2J Automotive Film Capacitor Specifications:
- Capacitance: 6.8uF
- Voltage DC: 400 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dimensions: Length 41.5mm ±0.3/ -0.7mm, Height 40mm ±0.1/ -0.7mm, Lead Spacing 37.5mm ±0.4mm
- Dielectric: Metallized Polypropylene
- Features: Automotive Grade, Pulse
- Lead Type: Wire Leads
- RoHS Compliant: Yes
- Qualification: AEC-Q200
- Insulation Resistance: 4.4 GOhms
- Dissipation Factor: 0.1% at 1kHz
- Ripple Current: Up to 900mA
- Inductance: 20 nH
Buy the Buy KEMET Automotive Capacitor Part Number R75MW468050H2J Online
Purchase the KEMET automotive-grade metallized polypropylene film capacitor, model R75MW468050H2J, online today. This reliable 6.8uF, 400VDC capacitor is ideal for pulse and automotive applications. It features excellent insulation resistance, low dissipation factor, and is RoHS compliant. Designed with wire leads and qualified under AEC-Q200, it ensures durability in demanding conditions. Perfect for engineers needing high-performance, long-lasting capacitors that meet strict automotive standards. Order now and secure dependable performance for your critical projects.
Order your KEMET Series R75MW468050H2J capacitor today and enhance your automotive and pulse application projects with dependable quality and reliable performance.
