KEMET R75PF156050H0J Automotive Film Capacitor
The R75PF156050H0J is a high-quality metallized polypropylene film capacitor designed for automotive applications and pulse resilience. Featuring a capacitance of 5600 pF with a 5% tolerance, a voltage rating of 630 VDC, and a temperature range from -55°C to +125°C, it is ideal for automotive-grade circuits requiring reliability and stability. Its radial lead configuration and compact dimensions of approximately 13mm in length and 9mm in height make it easy to incorporate into various electronic systems, ensuring durability under demanding conditions.
KEMET R75PF156050H0J Automotive Film Capacitor Specifications:
- Capacitance: 5600 pF
- Capacitance Tolerance: 5%
- Voltage DC: 630 VDC
- Voltage AC: 250 VAC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dimensions: Length approximately 13mm +0.2/-0.5mm, Height approximately 9mm +0.1/-0.5mm
- Lead Spacing: 10mm
- Material: Metallized Polypropylene
- Features: Automotive Grade, Pulse resistant
- RoHS Compliant: Yes
- Insulation Resistance: 100 GOhms
- Dissipation Factor: 0.04% at 1kHz
- Resistance: 142.1 mOhms at 100 kHz
- Ripple Current: 90°C, 11A
- Inductance: 9nH
- Certification: AEC-Q200 qualified
Buy the KEMET R75PF156050H0J – Reliable Automotive Film Capacitor for Industrial Applications
Purchase the KEMET R75PF156050H0J today for dependable performance in automotive and industrial electronics. This high-quality metallized polypropylene capacitor offers excellent stability, a capacitance of 5600 pF, a voltage rating of 630 VDC, and the robust durability you need for demanding applications. Its compact radial design, operating temperature from -55°C to +125°C, and compliance with industry standards ensure outstanding reliability. Buy online now to enhance your circuitry with proven, long-lasting performance and ensure your project’s success.
Get KEMET R75PF156050H0J today—built for automotive reliability and long-lasting pulse performance.
Frequently Asked Questions
Where can I buy KEMET R75PF156050H0J?
You can click on the BUY or RFQ button to purchase R75PF156050H0J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75PF156050H0J?
You can download the R75PF156050H0J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75PF156050H0J?
KEMET
