KEMET R75PI227050H0J Automotive Grade Capacitor
The R75H series is a metallized polypropylene film capacitor designed for automotive applications, offering excellent pulse handling and RoHS compliance. It features a radial lead style with wire leads, rated at 0.027 uF with a 5% tolerance, and rated for 630 VDC operation at a maximum temperature of 105°C. Its compact 18mm length with lead spacing of 15mm makes it suitable for a range of automotive and industrial electronic circuits requiring high reliability and safety standards. The capacitor also features low loss, high insulation resistance, and suitability for pulse applications, making it ideal for demanding environments.
KEMET R75PI227050H0J Automotive Grade Capacitor Specifications:
- Series: R75H
- Dielectric: Metallized Polypropylene
- Type: Radial
- Features: Automotive Grade, Pulse
- RoHS: Yes
- Lead Type: Wire Leads
- Qualification: AEC-Q200
- Component Weight: 1.4g
- Capacitance: 0.027 uF
- Tolerance: 5%
- Voltage AC: 250 VAC
- Voltage DC: 630 VDC
- Temperature Range: -55/+125°C
- Rated Temperature: 105°C
- Dissipation Factor: 0.04% at 1kHz
- Insulation Resistance: 100 GOhms
- Packaging: Bag, 1000 units
- Resistance: 176.8 mOhms at 100kHz
- Inductance: 10 nH
- Lead Length: 18mm +0.3/-0.5mm
- Lead Spacing: 15mm
- Maximum Voltage: 1000 V
- Operating Frequency Range: Up to 100kHz
Buy the KEMET R75P1227050H0J – Reliable Automotive Grade Capacitor for Industrial Applications
Secure the KEMET R75P1227050H0J capacitor online today—engineered for high pulse and transient applications with excellent electrical stability and reliability. Perfect for automotive, industrial, and electronic applications requiring high voltage withstand, low loss, and superior insulation resistance. Its compact radial design with wire leads makes installation easy and space-efficient. Designed to operate at up to 630 VDC and withstand temperatures from -55°C to +125°C, this capacitor ensures durable performance and consistent operation across harsh environments, making it an ideal choice for demanding electronic systems.
Get KEMET R75P1227050H0J today—built for high reliability and pulse performance in automotive and industrial circuits.
Frequently Asked Questions
Where can I buy KEMET R75PI227050H0J?
You can click on the BUY or RFQ button to purchase R75PI227050H0J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75PI227050H0J?
You can download the R75PI227050H0J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75PI227050H0J?
KEMET
