KEMET R75PI256050H3J film capacitor
The R75H series film capacitor features metallized polypropylene dielectric, automotive-grade pulse capability, and RoHS compliance. This radial component offers a capacitance of 0.056 microfarads with a 5% tolerance, rated for 630 VDC and operating at temperatures from -55°C to +125°C. Designed for reliable use in automotive and high-voltage pulse applications, it includes wire leads with a lead spacing of 15mm. The capacitor's compact size, dielectric material, and high voltage rating make it suitable for demanding electronic circuits requiring stability and durability.
KEMET R75PI256050H3J film capacitor Specifications:
- Capacitance: 0.056 uF
- Voltage DC: 630 VDC
- Voltage AC: 250 VAC
- Dielectric: Metallized Polypropylene
- Lead Spacing: 15mm
- Lead Type: Wire Leads
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dissipation Factor: 0.04% at 1kHz, 0.06% at 10kHz, 0.25% at 100kHz
- Insulation Resistance: 100 GOhms
- Resistance: 48.3 mOhms at 100kHz
- Operating Frequency: High pulse applications
- Dimensions: Length 18mm +0.3/-0.5mm
Buy the Buy KEMET Film Capacitor Part Number R75PI256050H3J Online
Order the KEMET film capacitor R75PI256050H3J online today and benefit from its high-voltage rating, excellent pulse handling, and temperature stability. This automotive-grade capacitor features metallized polypropylene for durability, making it ideal for demanding electronic circuits requiring stable capacitance, low-loss performance, and RoHS compliance. With its radial lead style and precise dimensions, it ensures easy installation and reliable operation across a wide temperature range, suitable for high-performance applications in automotive, industrial, and power systems. Purchase now to enhance your electronic projects.
Buy KEMET R75PI256050H3J now and experience reliable automotive-grade performance in pulse applications.
Frequently Asked Questions
Where can I buy KEMET R75PI256050H3J?
You can click on the BUY or RFQ button to purchase R75PI256050H3J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75PI256050H3J?
You can download the R75PI256050H3J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75PI256050H3J?
KEMET
