KEMET R75PI312050H3J Automotive Film Capacitor
The R75H series is a high-quality metallized polypropylene film capacitor designed for automotive and pulse applications. It features a 0.12uF capacitance with a 5% tolerance, rated to withstand up to 630VDC and operate within a temperature range of -55°C to +125°C. Its radial lead configuration, compact dimensions, and robust insulation resistance make it ideal for demanding electronic circuits. Certified to AEC-Q200 standards, it ensures reliability in automotive environments, with low dissipation factor and ripple current capacity for enhanced performance and durability.
KEMET R75PI312050H3J Automotive Film Capacitor Specifications:
- Series: R75H
- Dielectric: Metallized Polypropylene
- Type: Radial
- Features: Automotive Grade, Pulse
- RoHS: Yes
- Lead Type: Wire Leads
- Dimensions: Length 18mm ±0.5mm, Height 13.5mm +0.1/-0.5mm, Lead Spacing 15mm
- Capacitance: 0.12uF
- Capacitance Tolerance: 5%
- Voltage AC: 250 VAC
- Voltage DC: 630 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dissipation Factor: 0.05% at 1kHz, 0.08% at 10kHz
- Insulation Resistance: 100 GOhms
- Resistance: 33.2mOhms at 100KHz
- Ripple Current: 900mA
- Inductance: 10 nH
Buy the KEMET R75PI312050H3J – Reliable Capacitors for Industrial Applications
Purchase the KEMET R75H Series automotive film capacitor online today and enjoy a highly reliable component that ensures stable performance in demanding electronic circuits. With a capacitance of 0.12uF, rated at 630VDC, and capable of operating from -55°C to +125°C, this high-quality capacitor is ideal for automotive and pulse applications. Its robust insulation, radial lead design, and compliance with automotive standards like AEC-Q200 make it essential for engineers seeking durable and high-performance components. Order now for fast delivery and elevate your electronic designs.
Buy KEMET R75PI312050H3J now and experience unmatched reliability and performance in automotive and pulse circuit applications.
Frequently Asked Questions
Where can I buy KEMET R75PI312050H3J?
You can click on the BUY or RFQ button to purchase R75PI312050H3J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75PI312050H3J?
You can download the R75PI312050H3J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75PI312050H3J?
KEMET
