KEMET R75RR327050H4J Automotive Polypropylene Capacitor
The R75H series capacitor by KEMET is an automotive-grade metallized polypropylene film capacitor designed for pulse applications and high reliability. With a capacitance of 0.27 uF and a voltage rating of 1250 VDC, it is suitable for demanding automotive environments. The component features radial wire leads, operates within a temperature range of -55°C to +125°C, and complies with RoHS and AEC-Q200 standards. Its compact dimensions and high insulation resistance ensure durability and performance in electronic circuits requiring precise energy storage and filtering.
KEMET R75RR327050H4J Automotive Polypropylene Capacitor Specifications:
- Capacitance: 0.27 uF
- Capacitance Tolerance: 5%
- Voltage DC: 1250 VDC
- Voltage AC: 600 VAC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dimensions: Length 32mm +0.3/-0.7mm, Height 18mm +0.2/0.7mm, Lead Spacing 27.5mm +/-0.4mm
- Dielectric Material: Metallized Polypropylene
- Features: Automotive Grade, Pulse withstand
- RoHS Compliant: Yes
- Lead Type: Wire Leads
- Resistance: 17.7 mOhms (100KHz)
- Dissipation Factor: 0.05% (1kHz), 0.08% (10kHz)
- Insulation Resistance: 100 GOhms
- Maximum dV/dt: 750 V/μs
- Inductance: 18 nH
- Packaging: Bulk, Bag
- Component Weight: 12.3g
Buy the KEMET R75RR327050H4J – Reliable Automotive-grade Polypropylene Capacitor for Industrial Applications
Purchase the KEMET automotive-grade polypropylene capacitor today to ensure high reliability and performance in your electronic applications. With a capacitance of 0.27 uF and a voltage rating of 1250 VDC, this high-quality component is perfect for pulse and filtering circuits in automotive and industrial environments. Its radial wire leads and RoHS compliance make installation and integration straightforward while providing excellent durability across wide temperature ranges. Order now for fast delivery and guarantee your circuits operate at peak efficiency with trusted components.
Get KEMET R75RR327050H4J today—built for automotive reliability and pulse applications.
Frequently Asked Questions
Where can I buy KEMET R75RR327050H4J?
You can click on the BUY or RFQ button to purchase R75RR327050H4J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75RR327050H4J?
You can download the R75RR327050H4J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75RR327050H4J?
KEMET
