KEMET R82DC3150AA60K Automotive Film Capacitor
The R82DC3150AA60K is a high-quality, automotive-grade metallized polyester stacked capacitor designed for reliable electronic applications. Featuring a capacitance of 0.15 microfarads with a 10% tolerance, it operates at a voltage of 63 VDC within a temperature range from -55°C to +105°C. Its compact radial design measures 7.2mm in length, 25mm in width, and 4mm in height, with lead spacing of 5mm. This capacitor's low dissipation factor of 0.8% at 1kHz ensures stability and efficiency in demanding environments, meeting RoHS and AEC-Q200 standards for automotive reliability.
KEMET R82DC3150AA60K Automotive Film Capacitor Specifications:
- Capacitance: 0.15 uF
- Capacitance Tolerance: 10%
- Voltage DC: 63 VDC
- Voltage AC: 40 VAC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Dimensions: Length 7.2mm ±0.2mm, Width 25mm ±0.1mm, Height 4mm +1.5mm
- Lead Spacing: 5mm
- Dissipation Factor: 0.8% at 1kHz
- Insulation Resistance: 15 GOhms
- Maximum dV/dt: 160 V/us
- Inductance: 7nH
- RoHS Compliant: Yes
- Qualifications: AEC-Q200
- Package Quantity: 3000 units
Buy the Buy KEMET R82DC3150AA60K Part Number R82DC3150AA60K Online
Purchase the KEMET R82DC3150AA60K capacitor online today to ensure high-quality, reliable performance in demanding automotive and electronic circuits. This metallized polyester stacked capacitor offers excellent stability, low dissipation factor, and robust insulation resistance, making it ideal for high-reliability applications. With a capacitance of 0.15 microfarads and a voltage rating of 63 VDC, it’s suitable for various electronic systems requiring durable and precise components. Order now for fast delivery and trusted performance.
Buy KEMET R82DC3150AA60K now and experience unmatched reliability and performance in automotive-grade capacitor applications.
Frequently Asked Questions
Where can I buy KEMET R82DC3150AA60K?
You can click on the BUY or RFQ button to purchase R82DC3150AA60K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R82DC3150AA60K?
You can download the R82DC3150AA60K datasheet or visit the KEMET website for support.
Who is the manufacturer of R82DC3150AA60K?
KEMET
