KEMET R82DC3680DQ60K film capacitor
The R82DC3680DQ60K is a high-quality automotive-grade film capacitor designed with metallized polyester stacking. It features 0.68 microfarads capacitance with a 10% tolerance, rated for 63VDC, and operates reliably within a temperature range of -55°C to +105°C. This radial lead component is suitable for multipurpose applications, including automotive electronics, with low dissipation factors and a compact form factor measuring approximately 7.2mm in length, 4.5mm in thickness, and 9.5mm in height. It is RoHS compliant and qualifies under AEC-Q200 specifications, ensuring durability and high performance.
KEMET R82DC3680DQ60K film capacitor Specifications:
- Capacitance: 0.68 uF
- Capacitance Tolerance: 10%
- Voltage DC: 63 VDC
- Voltage AC: 40 VAC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Dimensions: Length 7.2mm +0.3mm, Height 9.5mm +0.1mm, Thickness 4.5mm +0.1mm
- Lead Spacing: 5mm
- Weight: 0.62g
- Dissipation Factor: 0.8% at 1kHz, 1.2% at 10kHz
- Inductance: 7nH
- Max Voltage: 160 V/us
- RoHS Compliant: Yes
- Qualifications: AEC-Q200
- Packaging: Ammo box, 360x340x59mm, 1900 pieces maximum
Buy the KEMET R82DC3680DQ60K – Reliable Capacitor for Industrial Applications
Purchase the KEMET R82DC3680DQ60K film capacitor online today and ensure your automotive or industrial electronic project benefits from proven durability, high performance, and reliable operation. Known for its metallized polyester construction, this capacitor offers a 0.68 microfarad capacitance at 63VDC, with excellent stability in a compact radial form factor. Suitable for multipurpose applications, it meets all relevant safety standards, including RoHS and AEC-Q200 certifications. Buying online guarantees fast delivery, competitive pricing, and trusted quality for your critical automotive and industrial needs.
Get KEMET R82DC3680DQ60K today—built for automotive-grade reliability and long-lasting performance.
Frequently Asked Questions
Where can I buy KEMET R82DC3680DQ60K?
You can click on the BUY or RFQ button to purchase R82DC3680DQ60K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R82DC3680DQ60K?
You can download the R82DC3680DQ60K datasheet or visit the KEMET website for support.
Who is the manufacturer of R82DC3680DQ60K?
KEMET
