KEMET R82EC1470CK50J Automotive Film Capacitor
The R82EC1470CK50J is an automotive-grade metallized polyester stacked film capacitor designed for versatile electronic applications. It offers a capacitance of 4700 pF with a 5% tolerance, rated for 100 VDC and an operational temperature range from -55°C to +105°C. This capacitor features wire leads, dimensions of 7.2mm length, 2.5mm height, and 5mm lead spacing, making it suitable for automotive and general industrial use. Its low dissipation factor and high insulation resistance ensure reliable performance in demanding environments.
KEMET R82EC1470CK50J Automotive Film Capacitor Specifications:
- Capacitance: 4700 pF
- Capacitance Tolerance: 5%
- Voltage DC: 100 VDC
- Voltage AC: 63 VAC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Material: Metallized Polyester Stacked
- Dimensions: Length 7.2mm ±0.2mm, Height 2.5mm ±0.1mm, Lead Spacing 5mm
- Insulation Resistance: 15 GOhms
- Dissipation Factor: 0.8% at 1kHz, 1.2% at 10kHz
- Inductance: 7 nH
- Packaging: T&R, Quantity: 2500
- Qualifications: AEC-Q200, RoHS Compliant
- Lead: Wire leads
- Weight: 0.23g
- Max dVidt: 200 V/μs
Buy the Buy KEMET R82EC1470CK50J Part Number 4700 pF Automotive Capacitor Online
Discover the KEMET R82EC1470CK50J automotive-grade metallized polyester stacked film capacitor, offering 4700 pF capacitance at 100 VDC with a 5% tolerance. Its compact dimensions and wire leads make it ideal for automotive and industrial applications. Designed to operate reliably from -55°C to +105°C, this capacitor features low dissipation factor, high insulation resistance, and RoHS compliance. Easy to order online, ensuring you get a durable, high-performance component for your electronic projects or vehicle systems.
Get KEMET R82EC1470CK50J today—engineered for automotive reliability and precision performance.
