KEMET R82EC3470Z370J Film Capacitor
The R82EC3470Z370J is an automotive-grade metallized polyester stacked film capacitor designed for electronic applications requiring high reliability. Featuring a capacitance of 0.47 microfarads with a tolerance of 5%, it operates at 100 VDC and withstands temperatures from -55°C to +105°C, with a rated temperature of 85°C. Its robust construction includes wire leads, a radial style, and RoHS compliance, making it suitable for automotive and industrial electronics where space economy and durability are critical. The capacitor offers low dissipation factor and high insulation resistance, ensuring optimal performance.
KEMET R82EC3470Z370J Film Capacitor Specifications:
- Capacitance: 0.47 uF
- Capacitance Tolerance: 5%
- Voltage DC: 100 VDC
- Voltage AC: 63 VAC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Dimensions: Length 7.2mm +0.3mm, Height 9.5mm +0.1mm, Thickness 4.5mm +0.1mm, Lead Spacing 5mm +/-0.4mm
- Lead Type: Wire Leads
- Dielectric: Metallized Polyester Stacked
- Body Style: Radial
- Dissipation Factor: 0.8% at 1kHz, 1.2% at 10kHz
- Insulation Resistance: 10.6383 GOhms
- Inductance: 7nH
- RoHS Compliant: Yes
- Qualification: AEC-Q200
- Weight: 0.62g
Buy the KEMET Series R82 Capacitor: Metallized Polyester Stacked 0.47uF 100VDC
Purchase the KEMET R82EC3470Z370J today to ensure high-quality performance in automotive and industrial electronics. This metallized polyester film capacitor offers 0.47 microfarads of capacitance at 100VDC, with a temperature rating from -55°C to +105°C and a rated temperature of 85°C. Its radial design with wire leads ensures easy installation. Built adhering to RoHS standards, it features a low dissipation factor and high insulation resistance for reliable operation in demanding environments. Order now for superior durability and performance.
Get KEMET R82EC3470Z370J today—built for automotive reliability and long-lasting performance.
Frequently Asked Questions
Where can I buy KEMET R82EC3470Z370J?
You can click on the BUY or RFQ button to purchase R82EC3470Z370J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R82EC3470Z370J?
You can download the R82EC3470Z370J datasheet or visit the KEMET website for support.
Who is the manufacturer of R82EC3470Z370J?
KEMET
