KEMET T494A104K035AT Tantalum Capacitor
The T494 series SMD Tantalum Capacitors are designed for highly automated surface-mount processes. They meet or exceed EIA standard 535BAAC, featuring symmetrical, compliant terminations and laser-marked cases for precise identification. Offering excellent wetting, they support a capacitance of 0.1µF with 10% tolerance and voltage ratings from 2.5V to 50V. Constructed with low ESR and tested for surge current, these halogen-free capacitors are moisture sensitive level 1 compliant, ideal for compact, high-reliability electronic applications requiring stable performance and easy surface-mount assembly.
KEMET T494A104K035AT Tantalum Capacitor Specifications:
- Capacitance: 0.1µF
- Capacitance Tolerance: 10%
- Voltage DC: 35 V
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- Dissipation Factor: 4% at 120Hz 25°C
- Resistance: 10 Ohms (LOOkHz 25°C)
- Ripple Current: 87mA rms (100kHz 25°C), 34.8mA rms (125°C)
- Leakage Current: 0.5µA (5 minutes 25°C)
- Enclosure: Molded, SMD, low ESR
- Termination: Tin
- Dimensions: Length 3.2mm ±0.2mm, Width 1.6mm ±0.2mm, Height Max 1.8mm
- Packaging: T&R, 178mm, Quantity 2000 units
- Features: Low ESR, halogen-free, surge tested, RoHS compliant
Buy the KEMET Series 1494 Tantalum Capacitor: T494A104K035AT
Secure your supply with KEMET T494A104K035AT tantalum capacitor, engineered for high reliability and low ESR in surface-mount technology. This compact, halogen-free component supports automated assembly lines, meeting strict industry standards. It offers a capacitance of 0.1µF with 10% tolerance and 35V voltage rating. Suitable for space-constrained designs, it ensures stable performance and long service life in demanding electronic applications. Order online today and benefit from fast delivery, high quality, and dependable performance for your projects.
Get KEMET T494A104K035AT today—designed for reliable surface-mount applications with low ESR and high surge current capability.
Frequently Asked Questions
Where can I buy KEMET T494A104K035AT?
You can click on the BUY or RFQ button to purchase T494A104K035AT from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T494A104K035AT?
You can download the T494A104K035AT datasheet or visit the KEMET website for support.
Who is the manufacturer of T494A104K035AT?
KEMET
