KEMET T494A106M016AT Tantalum Capacitor
The T494A106M016AT is a compact, low ESR SMD tantalum capacitor designed for reliable use in electronic circuits. It features a 10 uF capacitance with a 20% tolerance, capable of operating up to 125°C with a maximum voltage of 16 VDC. Its MnO2 dielectric provides excellent stability and reduced ripple resistance, making it suitable for high-performance applications. The package is a 3216 molded chip with tin termination, weighing only 58.6mg, ideal for space-constrained designs requiring durable, long-lasting components with a shelf life of 156 weeks.
KEMET T494A106M016AT Tantalum Capacitor Specifications:
- Capacitance: 10 uF
- Capacitance Tolerance: 20%
- Voltage DC: 16 V
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- Dissipation Factor: 8% at 120Hz 25°C
- Resistance: 3 Ohms at 100kHz 25°C
- Ripple Current: 142.2 mA rms at 85°C, 63.2 mA rms at 125°C
- Leakage Current: 1.6 μA for 5 minutes at 25°C
- Dimensions: Length 3.2mm ±0.2mm, Width 1.6mm ±0.2mm, Height Max 1.8mm, Footprint 3216
- Termination: Tin
- RoHS Compliant: Yes
- Packaging: T&R, 178mm, Quantity: 2000 units
- Series: 1494
- Dielectric: MnO2 Tantalum
- Style: SMD Chip
- Features: Low ESR
- Shelf Life: 156 Weeks
- MSL: Level 1
Buy the KEMET Series 1494 Low ESR Tantalum Capacitor: T494A106M016AT
Purchase the KEMET T494A106M016AT tantalum capacitor online today to ensure your project benefits from high stability, low ESR, and excellent reliability. This 10 uF, 16 VDC SMD component features a compact 3216 molded package, making it ideal for space-sensitive applications. With a shelf life of 156 weeks and RoHS compliance, it guarantees long-lasting performance. Trust our fast, secure online ordering process to deliver top-quality components directly to your workspace, supporting your electronic manufacturing needs efficiently and confidently.
Buy KEMET T494A106M016AT now and experience unmatched reliability and performance in high-quality SMD tantalum capacitors for your electronic designs.
Frequently Asked Questions
Where can I buy KEMET T494A106M016AT?
You can click on the BUY or RFQ button to purchase T494A106M016AT from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T494A106M016AT?
You can download the T494A106M016AT datasheet or visit the KEMET website for support.
Who is the manufacturer of T494A106M016AT?
KEMET
