KEMET T494C106K016AT Tantalum Capacitor
The T494 series Surface Mount Tantalum Capacitor is designed for automated manufacturing, featuring RoHS compliance and standard tin terminations. It offers low ESR, high reliability, and excellent solderability, with capacitance ratings from 10uF and rated voltage of 16V. Suitable for precision electronic circuits, it supports a temperature range of -55°C to +125°C and complies with industry standards like EIA 535BAAC. Packaged in halogen-free epoxy, with optional gold or tin-lead terminations, it’s ideal for applications requiring high quality and reliable performance.
KEMET T494C106K016AT Tantalum Capacitor Specifications:
- Capacitance: 10 uF
- Capacitance Tolerance: 10%
- Voltage DC: 16 V
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- Dissipation Factor: 6% at 120Hz 25°C.
- Resistance: 0.6 Ohms at 100kHz 25°C
- Ripple Current: 385.2 mA (rms, 85°C)
- Leakage Current: 1.6 uA (5min, 25°C)
- Dimensions: Length 6mm ±0.3mm, Width 3.2mm ±0.3mm, Height Max 2.8mm
- Terminations: Tin-plated, optional gold or tin-lead
- RoHS Compliant: Yes
- Packaging: T&R, 178mm, Quantity: 500
- Features: Low ESR, Molded, SMD, RoHS compliant
Buy the KEMET Series 1494 Tantalum Capacitor: T494C106K016AT
Enhance your electronic projects with the high-performance T494 series Tantalum Capacitor from KEMET. Featuring 10uF capacitance, 16V rating, and a broad operating temperature range of -55°C to +125°C, this SMD component is perfect for high-reliability applications requiring low ESR and high consistency. Made with RoHS-compliant materials and packaged in halogen-free epoxy, it ensures safety and sustainability. Order online today and give your devices the dependable power they need for optimal performance and long-term durability.
Order your KEMET Series 1494 Tantalum Capacitor T494C106K016AT today and equip your circuits with reliable, low ESR performance for demanding applications.
Frequently Asked Questions
Where can I buy KEMET T494C106K016AT?
You can click on the BUY or RFQ button to purchase T494C106K016AT from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T494C106K016AT?
You can download the T494C106K016AT datasheet or visit the KEMET website for support.
Who is the manufacturer of T494C106K016AT?
KEMET
