KEMET T495D477K006ATE125 Tantalum Capacitor
The T495 series capacitors are low ESR, surge robust manganese dioxide MnO₂ polarized tantalum chip capacitors. Designed for demanding applications, these capacitors handle high surge and ripple currents effectively, offering low ESR, high ripple current capacity, excellent stability, and resistance to inrush currents. Manufactured with proprietary materials and electrical conditioning, they provide reliable performance in various environments. Available in capacitance from 0.1µF to 1000µF, with case sizes including 1206, 1210, 2312, 2917, and 2924. They operate from -55°C to 125°C and meet industry standards.
KEMET T495D477K006ATE125 Tantalum Capacitor Specifications:
- Capacitance: 470 uF
- Capacitance Tolerance: 10%
- Voltage DC: 6.3 V (85°C), 4.22 V (125°C)
- Dimensions: Length 4.3mm +/-0.3mm, Height 2.8mm +/-0.3mm, Width 4.3mm +/-0.3mm
- Operation Temperature Range: -55°C to +125°C
- Dielectric: MnO2 Tantalum
- Series: T495
- Style: SMD Chip
- Rated Temperature: 85°C
- Dissipation Factor: 12% at 120Hz 25°C
- Resistance: 125 mOhms at 0.1kHz, 25°C
- Ripple Current: 438 mA at 85°C
- Leakage Current: 29.6 μA at 25°C
- RoHS Compliant: Yes
- Termination: Tin
- Shelf Life: 156 Weeks
- MSL: 1
- Packaging: T&R, 178mm, Quantity: 500
Buy the KEMET 7495 – Reliable Tantalum Capacitors for Industrial Applications
Purchase the KEMET T495D477K006ATE125 tantalum capacitor online today—engineered for high surge and ripple current applications. This low ESR, manganese dioxide dielectric capacitor features robust construction, stable performance across a wide temperature range, and high reliability. Perfect for demanding industrial electronics, it offers excellent capacitance stability and high current handling, ensuring optimal circuit performance. Order now to enjoy fast shipping and secure online purchasing, making your electronic projects or manufacturing processes more efficient with trusted, high-quality components.
Get KEMET 7495 today—built for precision and long-lasting durability in demanding electronic environments.
Frequently Asked Questions
Where can I buy KEMET T495D477K006ATE125?
You can click on the BUY or RFQ button to purchase T495D477K006ATE125 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T495D477K006ATE125?
You can download the T495D477K006ATE125 datasheet or visit the KEMET website for support.
Who is the manufacturer of T495D477K006ATE125?
KEMET
