KEMET T510X226K050ATE075 tantalum capacitor
The T510 series multiple anode manganese dioxide MnO₂ surface-mount tantalum capacitor is ideal for high-demand electronic applications needing high surge and ripple current endurance. Renowned for reliability, these capacitors feature low ESR, stable capacitance, and resistance to inrush currents due to multiple anodes and rigorous electrical conditioning. They meet or surpass EIA Standard 535BAAC, offer optional gold-plated terminations, and undergo extensive surge and aging tests. Suitable for demanding industrial uses, they have a capacitance range of 10μF to 100μF, with dimensions optimized for surface-mount applications, ensuring durability and high performance.
KEMET T510X226K050ATE075 tantalum capacitor Specifications:
- Capacitance: 22 μF
- Capacitance Tolerance: 10%
- Voltage DC: 50 VDC (85°C), 33.5 VDC (125°C)
- Dimensions: Length 7.3mm ±0.3mm, Width 4.3mm ±0.3mm, Height 4mm ±0.3mm
- Rated Temperature: 85°C
- Temperature Range: -55°C to +125°C
- Dissipation Factor: 8% at 120Hz 25°C
- Failure Rate: N/A
- Equivalent Series Resistance: 75 mOhms at 100kHz 25°C
- Ripple Current: 1707.3 mA rms at 85°C
- Leakage Current: 11 μA at 25°C for 5 min
- Packaging: T&R, 178mm; Quantity: 500 units
- RoHS Compliant: Yes
- Terminations: Tin, optional gold-plated
- Compliance: Meets or exceeds EIA Standard 535BAAC
Buy the KEMET T510X226K050ATE075 – Reliable Tantalum Capacitor for Industrial Applications
Discover reliable, high-performance surface-mount tantalum capacitors designed for demanding industrial applications. The KEMET T510 series offers low ESR, excellent stability, and high surge current capability. With a capacitance range from 10μF to 100μF, these capacitors feature multiple anodes, optional gold terminations, and rigorous testing for durability. Ideal for power management, filtering, and high-reliability circuits, they ensure optimal electrical performance, longevity, and efficiency in industrial environments. Purchase online today to upgrade your electronic systems with trusted quality.
Get KEMET T510X226K050ATE075 today—built for high surge, ripple current, and long-lasting durability in demanding industrial circuits.
Frequently Asked Questions
Where can I buy KEMET T510X226K050ATE075?
You can click on the BUY or RFQ button to purchase T510X226K050ATE075 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T510X226K050ATE075?
You can download the T510X226K050ATE075 datasheet or visit the KEMET website for support.
Who is the manufacturer of T510X226K050ATE075?
KEMET
