KEMET T510X337M010ATE035 Tantalum Capacitor
The T510X337M010ATE035 is a high-quality SMD manganese dioxide (MnO2) tantalum capacitor designed for reliable performance in electronic circuits. It features a 330 uF capacitance with a 20% tolerance, rated at 10 VDC, and operates over a temperature range of -55°C to +125°C. The component has a low equivalent series resistance (ESR) of 35 mOhms and a molded, multi-anode design for improved stability. Ideal for power supplies, filtering, and decoupling applications, this capacitor complies with RoHS standards and is packaged in tape and reel for easy automated assembly.
KEMET T510X337M010ATE035 Tantalum Capacitor Specifications:
- Capacitance: 330 uF
- Capacitance Tolerance: 20%
- Voltage DC: 10 VDC (85°C), 6.7 VDC (125°C)
- Dimensions: Length 7.3mm ±0.3mm, Width 4.3mm ±0.3mm, Height 4mm ±0.3mm
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- ESR: 35 mOhms (100kHz 25°C)
- Leakage Current: 33 μA (25°C)
- Dissipation Factor: 6% at 120Hz 25°C
- Packaging: T&R, 178mm reel, 500 units
- RoHS Compliant: Yes
- Terminations: Tin
- Failure Rate: N/A
- Shelf Life: 156 Weeks
- MSL: 1
Buy the YAGEO Series T510 MnO2 Tantalum Capacitor: T510X337M010ATE035
Purchase the T510X337M010ATE035 tantalum capacitor online today for your electronic projects. This high-quality component offers 330uF capacitance, low ESR of 35 mOhms, and a rated voltage of 10VDC, making it ideal for power supplies, filtering, and decoupling. Its broad temperature range of -55°C to +125°C ensures reliable operation across various conditions. Packaged in tape and reel, it supports automated manufacturing and provides long-term stability, RoHS compliance, and excellent performance for industrial and consumer electronics.
Get YAGEO T510X337M010ATE035 today—built for reliable power filtering and long-lasting durability.
Frequently Asked Questions
Where can I buy KEMET T510X337M010ATE035?
You can click on the BUY or RFQ button to purchase T510X337M010ATE035 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T510X337M010ATE035?
You can download the T510X337M010ATE035 datasheet or visit the KEMET website for support.
Who is the manufacturer of T510X337M010ATE035?
KEMET
