KEMET T520C107M010ATE025 Tantalum Polymer Capacitor
The T520 series KO-CAP Organic Capacitor is a high-performance surface-mount polymer tantalum capacitor with low ESR, excellent high-frequency capacitance retention, and long lifespan. It features a conductive polymer cathode, combining low ESR and high ripple current capacity, making it ideal for DC-to-DC converters and decoupling in high-frequency circuits. The compact package conforms to EIA standards and is halogen-free, ensuring environmental safety. Suitable for general-purpose applications up to 10V DC, it offers reliability, durability, and excellent thermal stability for modern electronic devices.
KEMET T520C107M010ATE025 Tantalum Polymer Capacitor Specifications:
- Capacitance: 100 uF
- Capacitance Tolerance: 20%
- Rated Voltage: 10 VDC
- Temperature Range: -55°C to +105°C
- Height Max: 2.8 mm
- Dimensions: 3.2mm x 3.2mm x 2.8mm
- Low ESR: 25 mOhms at 100kHz 25°C
- Dissipation Factor: 8% at 120Hz 25°C
- Ripple Current: 2.6A RMS at 85°C, 650mA at 105°C
- Leakage Current: 100 μA (5 min at 25°C)
- Shelf Life: 52 Weeks
- ESR: Low ESR characteristic
- Termination: Tin
- Humidity: 90% RH, 500 hours, no damage
- Compliance: RoHS
Buy the KEMET Series T520 Tantalum Capacitor: T520C107M010ATE025
Order the KEMET T520 polymer tantalum capacitor today online and upgrade your electronic designs with a reliable, low ESR, high-capacity component. This surface-mount capacitor offers excellent high-frequency performance, long operational lifespan, and environmental safety thanks to halogen-free epoxy. Perfect for DC-DC converters, decoupling, and hold-up applications, it maintains high stability under demanding conditions. Enjoy quick delivery, trusted quality, and seamless online purchasing to enhance your circuit performance effortlessly.
Buy KEMET T520C107M010ATE025 now and experience unmatched reliability and performance in compact surface-mount packaging for demanding electronic applications.
Frequently Asked Questions
Where can I buy KEMET T520C107M010ATE025?
You can click on the BUY or RFQ button to purchase T520C107M010ATE025 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T520C107M010ATE025?
You can download the T520C107M010ATE025 datasheet or visit the KEMET website for support.
Who is the manufacturer of T520C107M010ATE025?
KEMET
