KEMET T520D477M006ATE015 Polymer Tantalum Capacitor
The T520 series KO-CAP organic capacitor by KEMET is a solid electrolytic SMD component with a conductive polymer cathode, offering extremely low ESR, excellent high-frequency performance, and a long operational lifespan. It features 470 microfarads capacitance with a 20% tolerance, rated at 6.3V DC, and operates within a temperature range of -55°C to +105°C. This high-reliability capacitor is ideal for DC-DC converters, bulk decoupling, and hold-up applications, incorporating halogen-free epoxy for safety and environmental considerations, suited for modern electronic circuit needs.
KEMET T520D477M006ATE015 Polymer Tantalum Capacitor Specifications:
- Capacitance: 470 uF
- Capacitance Tolerance: 20%
- Voltage DC: 6.3 V
- Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Resistance: 15 mOhms at 100kHz 25°C
- Dissipation Factor: 10% at 120Hz 25°C
- Dimensions: Length 7.3mm ±0.3mm, Width 4.3mm ±0.3mm, Height 2.4mm ±0.1mm
- Height Max: 3.1mm
- Life Expectancy: 2000 hours at 105°C
- Humidity: 90% RH for 500 hours, no damage
- Packaging: Tape & Reel, 178mm, quantity 500
- RoHS Compliant: Yes
- Termination: Tin-plated
- Flammability: UL 94V-0
- Material: Polymer, Molded, Halogen-Free epoxy
Buy the Buy KEMET T520D477M006ATE015 Part Number 470uF 6.3V Online
Secure your supply of the high-quality polymer tantalum capacitor from KEMET T520 series. With low ESR, excellent high-frequency stability, and a long operational life, this 470uF, 6.3V DC rated capacitor ensures optimal performance in DC-DC converters, decoupling, and hold-up applications. Its halogen-free molded design guarantees safety and environmental compliance. Perfect for engineers seeking reliable, compact, and efficient electronic solutions, this component ships quickly via our online store, ready to enhance your project's power management and signal stability needs.
Buy KEMET T520D477M006ATE015 now and experience unmatched reliability and performance for high-frequency power filtering and decoupling.
Frequently Asked Questions
Where can I buy KEMET T520D477M006ATE015?
You can click on the BUY or RFQ button to purchase T520D477M006ATE015 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T520D477M006ATE015?
You can download the T520D477M006ATE015 datasheet or visit the KEMET website for support.
Who is the manufacturer of T520D477M006ATE015?
KEMET
