KEMET T520V337M2R5ATE015 Polymer Tantalum Capacitor
This polymer tantalum surface-mount capacitor offers 330 microfarads of capacitance with a 20% tolerance, rated at 2.5V DC. It features low ESR, molded construction, and non-combustibility, making it ideal for high-reliability applications. With dimensions of approximately 7.3mm in length and a maximum height of 1.9mm, it operates within a temperature range of -55°C to +105°C. RoHS compliant, it has a dissipation factor of 10% at 120Hz and a shelf life of 52 weeks, suitable for various electronic circuits demanding low profile and stability.
KEMET T520V337M2R5ATE015 Polymer Tantalum Capacitor Specifications:
- Capacitance: 330 uF
- Capacitance Tolerance: 20%
- Voltage DC: 2.5 VDC at 105°C
- Dimensions: Length approximately 7.3mm, height maximum 1.9mm
- Operating Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Dissipation Factor: 10% at 120Hz 25°C
- Leakage Current: 82.5 uA (5 min, 25°C)
- Resistance: 15 mOhms at 100kHz 25°C
- Shelf Life: 52 weeks
- RoHS Compliant: Yes
- Packaging: T&R, 178mm, 4000 pieces per reel
Buy the KEMET T520V337M2R5ATE015 – Reliable Polymer Tantalum Capacitor for Industrial Applications
Order the KEMET polymer tantalum capacitor now for dependable performance in your electronic projects. This 330uF, 2.5V DC component features low ESR, molded construction, and RoHS compliance. Its compact size, operating temperature range of -55°C to +105°C, and excellent stability make it ideal for high-reliability applications requiring low profile design. Perfect for circuit boards, power supplies, and demanding electronics, you can purchase online easily and ensure your project benefits from the durable, high-quality design of this advanced capacitor. Buy now for fast delivery and trusted performance.
Get KEMET T520V337M2R5ATE015 today—built for reliable performance in demanding electronic circuits.
