KEMET T521B105M050ATE200 Polymer Tantalum Capacitor
The T521B105M050ATE200 is a 1 microfarad polymer tantalum SMD capacitor with low ESR, high voltage rating, and molded construction designed for reliable use in various electronic circuits. It features a compact footprint of 3.5mm x 2.8mm, with a height maximum of 2mm, and is rated for 50VDC at 105°C. The capacitor offers a 20% tolerance, low dissipation factor of 8% at 120Hz, and an operating temperature range of -55°C to +105°C, making it suitable for high-performance applications requiring stability and consistency.
KEMET T521B105M050ATE200 Polymer Tantalum Capacitor Specifications:
- Capacitance: 1uF
- Capacitance Tolerance: 20%
- Voltage DC: 50 VDC (105°C)
- Dimensions: Length 3.5mm ±0.2mm, Width 2.8mm ±0.2mm, Height max 2mm
- Dielectric: Polymer Tantalum
- Type: SMD Chip, Molded
- Temperature Range: -55°C to +105°C
- Dissipation Factor: 8% at 120Hz 25°C
- Leakage Current: 5 μA at 25°C
- Ripple Current: 250 mA at 85°C
- Resistance: 200 mOhms at 100kHz 25°C
- RoHS Compliant: Yes
- Termination: Tin
- Shelf Life: 52 Weeks
- MSL: 3
- Rating Temperature: 105°C
- Rated Life: 2000 hours at 105°C
- Humidty: 90% RH for 500 hours, no failure
- Packaging: T&R, 178mm, Quantity: 2000
Buy the KEMET Series T521 Tantalum Capacitor: T521B105M050ATE200
Buy the Polymer Tantalum Capacitor T521B105M050ATE200 online today to ensure reliable, stable performance in your electronic applications. With a compact size of 3.5mm x 2.8mm, it offers low ESR, high voltage capacity of 50VDC, and excellent temperature stability from -55°C to +105°C. Perfect for minimizing noise and enhancing circuit durability. Supported by RoHS compliance, tin termination, and a shelf life of 52 weeks, this capacitor is ideal for high-reliability, miniaturized electronics. Get yours today and enhance your project's performance with dependable power storage.
Order your KEMET Series T521 Tantalum Capacitor today and give your electronic projects the dependable low ESR performance they need.
Frequently Asked Questions
Where can I buy KEMET T521B105M050ATE200?
You can click on the BUY or RFQ button to purchase T521B105M050ATE200 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T521B105M050ATE200?
You can download the T521B105M050ATE200 datasheet or visit the KEMET website for support.
Who is the manufacturer of T521B105M050ATE200?
KEMET
