KEMET T521B106M025ATE100 Polymer Tantalum Capacitor
The T521 series organic surface-mount Tantalum Capacitor features a conductive polymer cathode, providing very low ESR and high capacitance retention at high frequencies. It combines low ESR of multilayer ceramic capacitors, high capacitance of electrolytic capacitors, and the volumetric efficiency of tantalum, all in a compact SMD package. Designed for high-voltage applications, it offers long-term reliability, high ripple current support, stable thermal performance, and an epoxy, halogen-free construction. It is surge current tested, suitable for demanding electronics, and ideal as a durable alternative to liquid electrolyte capacitors.
KEMET T521B106M025ATE100 Polymer Tantalum Capacitor Specifications:
- Capacitance: 10 uF
- Capacitance Tolerance: 20%
- Voltage Rating: 25 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dimensions: Length 3.5mm ±0.2mm, Width 2.2mm ±0.1mm, Height Max 2mm
- Ripple Current: 1410 mA (rms, 85°C)
- Leakage Current: 25 uA (5 min, 25°C)
- Dissipation Factor: 8% 120Hz 25°C
- Resistance: 100 mOhms (100kHz 25°C)
- Life: 2000 hours at 125°C
- Packaging: T&R, 2000 pcs per reel
- RoHS: Yes
- Halogen-free: Yes
- Termination: Tin
- Dielectric: Polymer Tantalum
- Series: T521
- Height Max: 2mm
Buy the Buy KEMET T521B106M025ATE100 Part Number T521B106M025ATE100 Online
Purchase the high-quality KEMET T521B106M025ATE100 polymer tantalum capacitor online today. Featuring low ESR, high voltage support, and a compact SMD package, it’s perfect for high-frequency, high-reliability electronic projects. Designed to withstand demanding conditions, it offers excellent long-term stability, high ripple current, and thermal performance. With surge current testing and halogen-free construction, this capacitor ensures durability and safety for critical applications. Shop now for fast delivery and trusted performance in your next design.
Order your KEMET Series T521B106M025ATE100 high-voltage polymer tantalum capacitor today and ensure reliable performance in your demanding electronic applications.
