KEMET T521B335M035ATE150 Polymer Tantalum Capacitor
The T521B335M035ATE150 is a polymer tantalum SMD chip capacitor designed for low ESR and high voltage applications. With a capacitance of 3.3 uF and a voltage rating of 35 VDC, this molded component offers stability from -55°C to +105°C. Its compact footprint of 3.5mm x 2.8mm height, combined with features like RoHS compliance, tin termination, and non-combustible low ESR, makes it suitable for high-reliability electronic circuits requiring minimal ESR, excellent stability, and durable performance in demanding environments.
KEMET T521B335M035ATE150 Polymer Tantalum Capacitor Specifications:
- Capacitance: 3.3 uF
- Capacitance Tolerance: 20%
- Voltage DC: 35 VDC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 105°C
- Dimensions: Length 3.5mm ±0.2mm, Width 2.8mm ±0.2mm, Height max 2mm
- ESR: 150 mOhms at 100 kHz 25°C
- Ripple Current: 290 mA at 85°C
- Leakage Current: 11.6 µA (min at 25°C)
- Humidity: 90% RH, 500 hours, no failure
- Packaging: T&R, 178mm, Quantity: 2000
- Termination: Tin
- RoHS Compliant: Yes
- Flammability: UL 94V-0
- Component Weight: 94.85 mg
- MSL: 3
- Shelf Life: 52 weeks
Buy the Buy KEMET T521B335M035ATE150 Part Number 335 3.3 uF 35 VDC Online
Purchase the KEMET T521B335M035ATE150 polymer tantalum capacitor online today. This compact SMD component provides low ESR, high voltage stability, and exceptional durability, ideal for demanding electronic applications. Featuring a capacitance of 3.3 uF at 35 VDC, it offers excellent performance from -55°C to +105°C. Its RoHS compliance, tin termination, and non-combustible design make it suitable for high-reliability circuits requiring minimal ESR, long lifespan, and robust operation in various environmental conditions. Order now for quick delivery and dependable performance.
Buy KEMET T521B335M035ATE150 now and experience unmatched reliability and superior low ESR performance for your high-reliability electronics.
Frequently Asked Questions
Where can I buy KEMET T521B335M035ATE150?
You can click on the BUY or RFQ button to purchase T521B335M035ATE150 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T521B335M035ATE150?
You can download the T521B335M035ATE150 datasheet or visit the KEMET website for support.
Who is the manufacturer of T521B335M035ATE150?
KEMET
